hot selling ball mill machine price from China manufacturer
application:
ball mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc, and the ball mill can grind various ores and other materials with dry type and wet type.
Advantages of ball mill:
1 Ball mill's Double-row self-aligning spherical roller bearing replaces babbit-lined bearing. Friction resistance is greatly lowered down, easy to start and 20-30% of energy is saved.
2.Ball mill's Grooved and ringed liner increases contacting surface between balls and ores, improving milling effect and saving energy through its lifting effect to the materials.
3. Ball mill's All-in-one frame is used in middle-sized or small-sized machinery, facilitating engineering construction and equipment installation.
4.Ball mill's Large discharging outlet and high capacity, discharge coarse particles, usually used in first stage milling.
5.The Energy-saving Cone Ball Mill can be used for grinding particles in the process of metal mineral resouces, such as gold, silver, iron, copper, lead, zinc etc., and non-metal mineral resources.
Main technical parameters:
Model | φ900 | φ1200 | φ1200 | φ1500 | φ1500 | φ1830 | φ2100 | |
Barrel inside dia. | mm | 900 | 1200 | 1200 | 1500 | 1500 | 1830 | 2100 |
Length | mm | 2100 | 2800 | 4500 | 3500 | 5700 | 3600 | 3600 |
Speed | r/min | 37.8 | 37 | 37 | 30 | 30 | 25.17 | 24.6 |
Power | kw | 15 | 30 | 55 | 75 | 90 | 130 | 180 |
Volume | m3 | 1.1 | 2-4 | 4-6 | 5-8 | 9 | 15 | 25 |
Capacity | t | 1.8 | 4 | 6.8 | 7.5 | 12 | 14.6 | 22.9 |
Feed size | mm | ≤20 | ≤25 | ≤25 | ≤25 | ≤25 | ≤25 | ≤25 |
Output size | mm | 0.075-0.3 | 0.075-0.3 | 0.075-0.3 | 0.075-0.3 | 0.075-0.3 | 0.075-0.3 | 0.75-0.3 |
Weight | t | 42 | 8.5 | 11.2 | 16.8 | 20.7 | 26 | 40 |
