Help CenterBall Mill Machine for Silicate, Building Materials, Refractory Materials
Related Products
-
Ball Mill Machine China Manufacturer SupplyUS$ 7,548 - 204,918MOQ: 1 Set -
China Yuhui Wet Type Ball Mill Grinding Machine ISO9001:2000US$ 7,548 - 204,918MOQ: 1 Set
-
2012 the Latest Design Ceramic Ball Mill MachineUS$ 7,548 - 204,918MOQ: 1 Set
-
On-hand Selling Cement Ball MillUS$ 100 - 8,888,888MOQ: 1 Set
-
Hot Selling Ball Mill Machine Price From China ManufacturerUS$ 7,548 - 204,918MOQ: 1 Set
Specifications
ball mill machine for silicate, building materials, refractory materials1.within 15 days delivery
2.low consumption 40%
ball mill machine for silicate, building materials, refractory materials
Ball mill Applications
Ball mill is mainly used in mining industry, cement industry, chemical industry and building industry. Mineral and raw material of middle-hardness in the dry or wet milling process.
Ball mill Specifications
1.Double-row self-aligning spherical rolling bearing replaces babbit-lined bearing. Friction resistance is greatly lowered down, easy to start and 20-30% of energy is saved.
2.Grooved and ringed liner increases contacting surface between balls and ores, improving milling effect and saving energy through its lifting effect to the materials.
3.All-in-one frame is used in middle-sized or small-sized machinery, facilitating engineering construction and equipment installation.
4.Large discharging outlet and high capacity, discharge coarse particles,usually used in first stage milling
Parameter of ball mill with rolling bearing
Model | Cylinder Diameter*Length(mm) | Capacity(t/h) | Motor Power(kw) |
MQYJ0909 | 900*900 | 0.22-1.07 | 11 |
MQYJ0918 | 900*1800 | 0.44-2.14 | 15 |
MQYJ1216 | 1200*1600 | 0.4-6.2 | 30 |
MQYJ1228 | 1200*2800 | 0.35-8.2 | 55 |
MQYJ1515 | 1500*1500 | 1. 4-4. 5 | 55 |
MQYJ1524 | 1500*2400 | 2.2-7.2 | 75 |
MQYJ1530 | 1500*3000 | 3.8-8 | 80 |
MQYJ1536 | 1500*3600 | 4.8-10 | 95 |
MQYJ1551 | 1500*5100 | 4.8-12 | 110 |
MQYJ1557 | 1500*5700 | 5-15 | 130 |
MQYJ1830 | 1800*3000 | 6-9 | 130 |
MQYJ1836 | 1800*3600 | 6.5-11 | 130 |
MQYJ1840 | 1800*4000 | 7-11 | 135 |
MQYJ1844 | 1800*4400 | 7.5-11.5 | 155 |
MQYJ2122 | 2100*2200 | 5-29 | 130 |
MQYJ2130 | 2100*3000 | 6.5-36 | 180 |
MQYJ2136 | 2100*3600 | 7.8-43.2 | 210 |
MQYJ2145 | 2100*4500 | 9.7-54 | 245 |
MQYJ2430 | 2400*3000 | 7.2-90 | 280 |
MQYJ2436 | 2400*3600 | 8.6-108 | 280 |
MQYJ2721 | 2700*2100 | 6.5-84 | 280 |
MQYJ2727 | 2700*2700 | 9-110 | 280 |
MQYJ2730 | 2700* 3000 | 10-122 | 380 |
MQYJ2736 | 2700*3600 | 13.3-161 | 380 |
MQYJ2740 | 2700*4000 | 12-160 | 400 |
MQYJ2745 | 2700*4500 | 15-181 | 400 |
Note: The technical parameters above are just for your reference. If there is any change, all parameters and overall dimension are subject to operating instructions. Any questions please feel free to contact us.
Our company established in the 1970s , Henan Yuhui Mining Machinery Co., Ltd has developed into a manufacturer specialized in producing mineral dressing equipment , sand making equipment, cement equipment, compound fertilize equipment .
