US$ 7,548 - 204,918 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Ball Mill
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Henan Yuhui Mining Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Ball Mill
Motor Type AC Motor
Power(W) different model
Capacity(t/h) different model
Place of Origin Henan, China
Brand Name Yuhui
Model Number many types
Dimension(L*W*H) different model
Weight different model
Certification ISO9001:2000
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

 Ball mill machine in stock for customers around the world

Brief introduction of ball mill machine:

 Ball Mill Machine is mainly used to grind materials in mineral,cement,refractory,chemical industry, etc.Ball Mill has dry and wet ways.When wet Ball Mill Machine works,certain water and other liquid will be added into materials to increase flowability of materials,so the capacity is increased.  When dry Ball Mill works,capacity is affected because material flowability is reduced,so absorbing wind device is needed on the outlet of Ball Mill Machine ,and then negative pressure is formed in the Ball Mill to increase flowability of material, so the capacity is increased.



Working principle of ball mill machine:

When the Ball Mill works,motor and speed reducer transmit torque force to big and small gears of Ball Mill Machine,so the barrel rotates.When the barrel rotates,Steel balls or other grinding media in the barrel are lifted to a certain height and fall down freely,so materials in the barrel are impacted.Grinding media mixing with materials impact and grind materials continuously.The grinding media and materials impact and grind each other when the Ball Mill Machine rotates continuously.The final product will be discharged from outlet when it meets the request,so the grinding process is finished.



Features of  ball mill machine:

1.Large application range,simple structure and convenient maintenance.

2.Large capacity and continuous work are very obvious.

3.Barrel lining and grinding media can apply various abrasive materials.

4.Installation and adjustment are very convenient and easy to be operated.



Technical Parameters of  ball mill machine:

Model

input size(mm)

Output size(mm)

Weight of ball(t)

Speed of bucket(r/min)

Power(kw)

Capacity(t/h)

Weight(kg)

900*1800

15

0.075-0.89

1.9

37

15

0.5-2

3400

900*2100

15

0.075-0.4

2.3

37

18.5

0.4-2

3900

900*3000

25

0.075-0.4

3.85

35

30

1.1-2.5

7780

1200*2400

25

0.075-0.4

4.6

35

30

1.3-3.2

8650

1200*2800

25

0.075-0.4

5.4

35

37

1.5-3.7

10020

1200*4500

25

0.075-0.4

8.6

35

45

2.7-6.79

14000

1500*3000

25

0.047-0.4

9

29

75

3.3-8.2

14122

1500*3500

25

0.047-0.4

10.5

29

75

3.3-8.5

15636

1500*4500

25

0.047-0.4

13.5

29

90

4.5-12

20000

1500*5700

25

0.047-0.4

17

29

110

2.6-14

25000

1830*3000

25

0.047-0.4

13.5

24

135

4-15

28000

1830*4500

25

0.047-0.4

20

24

155

4-19

32000

1830*7000

25

0.047-0.4

31.5

24

210

6-22

37500

2100*3000

25

0.047-0.4

18

22

210

6.4-28

40790

2100*4000

25

0.047-0.4

21.5

22

210

7.6-28

43454

2200*3600

25

0.047-0.4

25

21.7

245

5.2-32

44000

2200*7000

25

0.047-0.4

46

21.7

380

15-38

54000

2400*3600

25

0.047-0.4

28

21

320

8-60

47000

2400*4500

25

0.047-0.4

35

21

380

8.5-60

65000
