SRLZ 500/1000 High Speed Heating Cooling WPC Mixing Machine

Specifications

SRLZ 500/1000 High Speed Heating Cooling WPC Mixing Machine
1, CE certificat, ISO 9001
2, high speed mixer
3, machine in stoc

SRLZ 500/1000 High Speed Heating Cooling WPC Mixing Machine





The WPC mixing machine including following sections:

1, heating mixer

2, cooling mixer

3, small ladder







The features of our WPC machine

• Developed on the basis of advanced technique, the SRL-Z series mixer is mainly used for drying, dewatering and mixing for the wood plastic products.
• The spindle sealing equipment of good sealing and non-leakage has been awarded the national patent. The heating mixer has the heating function of self-friction and electricity.
• The pot cover adopts double-sealing layer.

• The cooling mixer adopts arched pot cover and specically-designed blade, which passes the test of static balance and dynamic balance.
• Combined with the heating mixing technique and cooling mixing technique, the SRL-Z mixer is the ideal processing equipment in WPC production.
• The material after heating mixing would turn into cooling mixer automatically, then the air would be exhausted and the material wouldn’t be blocking.



Total Volum	500/1000 litres
Valid volum	375/650 litres
Stir Speed	heating mixing blade 3 pieces; blade material: stainless steel
Rotary speed of heating mixing blade	heating mixing: 500/1000 rpm cooling mixing: 96 rpm
Heating mode	electricity / Self-friction automatic friction or electric heating
Cooling Mode	Water cooling
Mixing time	6-10 mins.
Cooling Time	10-15 mins.
Motor	Variable level multispeed three-phase asychronous motor
Motor parameters	56/76/15 kw
Water Consumption	6.9 t/h
Production Run	700-900 kg/h
Discharging Mode	Pneumatic
Overall dimension	4725*3000*4050 mm
Net Weight	5800 kgs



Wood Powder and PVC before Mixing Machine Processed:









Mixer PVC Wood Plastic Powder:







WE have rich experience in making wpc machine, our successful wpc projects as following:
1, WPC turnkey project in Romania, it is the first WPC manufacturer in Romania
2, WPC turnkey project for Australia
3, WPC turnkey project for Uzbekistan, it is the first WPC manufacturer in Uzbekistan
4, WPC turnkey project in Ecuador
5, WPC turnkey project in Lebanon
6, WPC turnkey project in Mexico
7, WPC turnkey project in Malaysia
8. WPC turnkey project in Indian
9. WPC turnkey project in China
10, WPC turnkey project in Algeria
11, WPC turnkey project in Russian
