Hot Sale Aluminum Tube filling and sealing machine
Features
This semi automatic aluminum tube filling and sealing machine which filling, tail-sealing and batch-number printing It is used for the products’ packing in the fields of medicine, daily chemical products, food and fine chemical industry, such as ointment, hair dyes, pigments, toothpastes, shoe polishes, and adhesives.
Work process
It is a manual feeding tube into mould, and use the indexing mechanism for the transmission and location and photoelectric detection and the metering pump for quantitative filling. The tail sealing and printing are finished at one time and the finished products are automatically pushed out.
Structural characteristics: This machine adopts piston mode to achieve precise filling and the measuring error is less than 1%. It has no liquid leak and its speed is adjustable. It also can be bidirectionally folded which is the most advanced horseshoe mechanism. It produces good sealed tails and its operation is simple. Its filling, sealing and printing are finished at one time. It thoroughly solves the problem of wiredrawing commonly existing in the producing process and the common fault of leaking at the tail after sealed. As for the special industry, it needs to be added with the gas protection device to prevent the solidification phenomenon occurring during transportation and storage.
Technical Parameter
1 Power supply :AC220±10% 50Hz
2 capacity :10-50 bottles/min
3 Tube diameters sealed: 10-35(mm)
4 pipe die position :16 pieces
5 power :1.1kw
6 hopper volume:40L
7 filling volume: 5ml-75ml 25ml-125ml
8 Precision : ±1%
9 Weight :250kg
10 Air source pressure : 0.6-0.7Mpa Air consumption 0.2M3/min (only use in the high viscosity material )
11 machine measure 1000×600×1700(mm)
