Automatic hose tube filling & sealing machine
The machine is suitable for soft tube tail-sealing and date-printing of accessory, pharmaceutical, food, chemical industry . Adopt the automatic intubation, automatic positioning, PLC control, hot air from the tube wall heating, the localization is accurate, can be automatically adjusted and displayed the filling dose , especially suitable for all-plastic pipe tail-sealing, beautiful appearance , sealing firmly .
Equipment main technical parameter list
Parameter name | Parameter value | |
Equipment name | Automatic hose tube filling and sealsing machine (12 station)
| |
Type number | SGF-50 | |
Electric source | 380V/220V(optional) | |
all | Hose materials | Plastic pipe, composite tube |
Filling range | 5ml-50ml,50-200ml(adjustable) | |
Filling accuracy | ≤±1% | |
Filling speed | 20-50 pcs/min | |
Hose diameter | Φ19-Φ50mm | |
Hose length | 220mm(Maximum length) | |
Work pressure | 0.55-0.65Mpa | |
motor | 1.1kw | |
Heat sealing power | 3.0kw | |
Physical size (length * width × * high) | 1850×950×1900mm | |
Machine weight | 850kg | |
Equipment main components configuration list
If you need more information and quotation about the machine.
please contact :Jerry
Skype :gymachine
Phone number /whatsapp/ wechat: 13825018778
