Hot sell metal hose sealing and filling machine
Metal hose sealing and filling machine
Metal hose sealing and filling machine , mainly with metal hose as packaging container material quantitative filling, sealing. This machine widely used in the pharmaceutical, cosmetic, food, chemical and other industries of product packaging. Such as: ointment, adhesive, AB rubber, neoprene, epoxy glue, skin cream, hair cream, boots oil, toothpaste, liquid or cream material filling and sealing.
Working process:
Artificial will metal hose inserted index plate header inside (16 station), the use of mechanical drive inversion, photoelectric detection, confirm that there is tube and plug put right, filling system began to automatic measuring filling and then seals the tail, print batch number, product exit.
Main technical parameters,
1, the power supply voltage: ac 220 v - 10% 50 hz
2, mechanical ability: 10 - 50 pcs/minutes (stepless speed adjustment)
3, suitable hose diameter: 10 - 35 (mm)
4, pipe die seat: 16
5, power: 1.1 kw
6, volume: 40 L
7, filling quantity: 5 ml - 75 ml 25 ml - 125 ml
8, measuring accuracy erro: plus or minus 1%
9, overall weight: 250 (Kg)
10, compressed air: pressure 0.6-0.7 Mpa, air demand: 0.2 M3 / min (only in the material is very thick, a drawing of the conditions of use.
11, outlook size: 1000 x 600 x 1700 (mm)
If you need more information and quotation about the machine.
please contact :Jerry
Skype :gymachine
Phone number /whatsapp/ wechat: 13825018778
