YUMO DRP-240-24 industrial power supply
Specifications
DRP-240-24 switching power supply 240w 24v 10a smps
1. CE ROHS approved
2. AC85-264V input
3. 83% efficiency
| MODEL | DR-240-12 | DR-240-24 | DR-240-48 | ||
| Output | DC Voltage | 12V | 24V | 48V | |
| Rated current | 20A | 10A | 5A | ||
| Current range | 0-20A | 0-10A | 0-5A | ||
| DC power | 240W | 240W | 240W | ||
| Voltage ADJ.range | 21.6~26.4V | 21.6~26.4V | 43.2~52.8V | ||
| Voltage tolerance | ±1% | ±1% | ±1% | ||
| Ripple and noise | 80mVp-p | 80mVp-p | 150mVp-p | ||
| Intet stability | ±0.5% | ±0.5% | ±0.5% | ||
| Load stability | ±1% | ±1% | ±1% | ||
| Intput | AC voltage range | 90~132VAC/170~264VAC 47~63Hz ; 240~370VDC | |||
| Current | 3.5A/115V 1.8A/230V | ||||
| Effi ciency | 85% | 84% | 85% | ||
| AC Inrush current | Cold-start current 30A/115V 60A/230V | ||||
| Leakage current | < 3.5mA/240VAC | ||||
| Protection | Overload | 105%~150% Type:pulsing hiccup shutdown Resete:auto recovery | |||
| Over voltage | 15~16.5V | 28~33V | 58~65V | ||
| Safety | Setup,rise,hold up time | 1000ms,60ms,50ms/230V | |||
| Vibration | 10~500Hz,2G 10min,/1 cycle | ||||
| Withstand voltage | Input and output internal:1.5KvAc,input and enclosure:1.5KvAc,Output and enclosure:0.5KvAc | ||||
| Isolation resistance | Input and output internal:Input and enclosure,Output and enclosure:500VDC/100MΩ | ||||
YUMO DRP-240-24 industrial power supply YUMO DRP-240-24 industrial power supply YUMO DRP-240-24 industrial power supply YUMO DRP-240-24 industrial power supply YUMO DRP-240-24 industrial power supply YUMO DRP-240-24 industrial power supply YUMO DRP-240-24 industrial power supply
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
