YUMO LM30 PNP NO NC range 15mm Inductive proximity sensor LM30-3015PC
Model explanation of proximity switch
| No. | Composition | Code and definition | |||||||||
| 1 | Switch category | LM:inductance type CM:capacitance type SM:Hall type AM:safety explosion-proof type XM:mimic linear type HM:reed type |
|||||||||
| 2 | Outward appearance code | :cylinder type F :angular column type and plane installation type | |||||||||
| 3 | Working voltage | 30:6-36VDC 310:5-24VDC 320:12-60VDC 20:90-250VAC 210:24-250VAC 220:380VAC 40:12-240VDC/24-240AC 50:Special voltage |
|||||||||
| 4 | Detection distance | 01:1mm 05:5mm 10:10mm | |||||||||
| 5 | Output form | N:three-wire DC NPN output P:three-wire DC PNP output L:two-wire DC output O:AC two-wire output W:AC three-wire output J:Relay contact outputNP:NPN+PNP double output |
|||||||||
| 6 | Output state | A:(ON)Normally open(NO) B:(NC)Normally close(NC) C:(NO+NC)normally open+normally close(NO+NC) MU:Mimic voltage MI:Mimic current |
|||||||||
| 7 | Subsidiary functions | T:with aviation connector Y:water proof,oil proof I:special requirement H:high temp resistane R:ring type |
|||||||||
| Structural category | Cylinder type | |||||
| Outward appearance code | LM18 | LM22 | LM30 | |||
| Outward appearance illustration | ||||||
| Flush | Detection distance | 5mm | 7mm | 10mm | ||
| DC 6~ 36 VDC | NPN | NO | LM18-3005NA | LM22-3007NA | LM30-3010NA | |
| NC | LM18-3005NB | LM22-3007NB | LM30-3010NB | |||
| NO+NC | LM18-3005NC | LM22-3007NC | LM30-3010NC | |||
| PNP | NO | LM18-3005PA | LM22-3007PA | LM30-3010PA | ||
| NC | LM18-3005PB | LM22-3007PB | LM30-3010PB | |||
| NO+NC | LM18-3005PC | LM22-3007PC | LM30-3010PC | |||
| Two wire system | NO | LM18-3005LA | LM22-3007LA | LM30-3010LA | ||
| NC | LM18 -3005LB | LM22 -3007LB | LM30 -3010LB | |||
| AC 90~ 250 VAC | SCR Controllable silicon | NO | LM18 -2005A | LM22 -2007A | LM30 -2010A | |
| NC | LM18-2005B | LM22-2007B | LM30-2010B | |||
| NO+NC | LM18 -2005C | LM22 -2007C | LM30 -2010C | |||
| Relay output | - | - | LM30-2010JC | |||
| Non-flush | Detection distance | 8mm | 10mm | 15mm | ||
| DC 6~ 36 VDC | NPN | NO | LM18-3008NA | LM22-3010NA | LM30-3015NA | |
| NC | LM18-3008NB | LM22-3010NB | LM30-3015NB | |||
| NO+NC | LM18-3008NC | LM22-3010NC | LM30-3015NC | |||
| PNP | NO | LM18-3008PA | LM22-3010PA | LM30-3015PA | ||
| NC | LM18-3008PB | LM22-3010PB | LM30-3015PB | |||
| NO+NC | LM18-3008PC | LM22-3010PC | LM30-3015PC | |||
| Two wire system | NO | LM18-3008LA | LM22-3010LA | LM30-3015LA | ||
| NC | LM18 -3008LB | LM22 -3010LB | LM30 -3015LB | |||
| AC 90~ 250 VAC | SCR Controllable silicon | NO | LM18 -2008A | LM22 -2010A | LM30 -2015A | |
| NC | LM18-2008B | LM22-2010B | LM30-2015B | |||
| NO+NC | LM18 -2008C | LM22 -2010C | LM30 -2015C | |||
| Relay output | - | - | LM30-2015JC | |||
| Control output | DC | 200mA | 200mA | 200mA | ||
| SCR/Relay | 300mA | 300mA/ 1A | ||||
| Output voltage dropDC/AC | DC>3V , AC<10V | |||||
| Consumption current | DC<15mA , AC<10mA | |||||
| Standard detected object | 18×18×1(A3 iron) | 22×22×1(A3 iron) | 30×30×1(A3 iron) | |||
| Repeated precision | 0.02 | 0.05 | 0.05 | |||
| DC/AC Response frequency | 200Hz/25Hz | 200Hz/15Hz | 200Hz/15Hz | |||
| Working environment temperature | -25 °C ~ + 75 °C | |||||
| Insulation resistance | 50MΩ | 50MΩ | 50MΩ | |||
| Shell material | Metal | Metal | Metal | |||
| Protection grade | IP67 | |||||
| Altemative mode at home and abroad | LJ 18A 3-8- | LJ 22A - - | E2E-X 18M | |||
YUMO LM30 PNP NO NC range 15mm Inductive proximity sensor LM30-3015PC YUMO LM30 PNP NO NC range 15mm Inductive proximity sensor LM30-3015PC YUMO LM30 PNP NO NC range 15mm Inductive proximity sensor LM30-3015PC YUMO LM30 PNP NO NC range 15mm Inductive proximity sensor LM30-3015PC
YUMO LM30 Inductive proximity sensor LM30-3015PC YUMO LM30 Inductive proximity sensor LM30-3015PC YUMO LM30 Inductive proximity sensor LM30-3015PC YUMO LM30 Inductive proximity sensor LM30-3015PC YUMO LM30 Inductive proximity sensor LM30-3015PC YUMO LM30 Inductive proximity sensor LM30-3015PC
Q:How to order our product ?
A:1).Please tell us the model and quantity and other request you need.
2).We make the PI for you.
3).After you confirm the PI, we arrange the order for you after receiving your payment.
4).After the goods finished, we send the goods out to you and tell you the tracking number.
5).We will track your goods until you receive the goods.
Q: What's your warranty ?
A: One years
Q: What's your contact information:
A: Our address: Liushi town, Zhejiang province, China. Sky-pe: benjaminying
Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.
Q: What's about MOQ?
A: First order MOQ=1pcs
Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C.
Q: If i want to release order, what's the process?
A: Thanks. You can send inquiry to us by alibaba, or send us by email, we will reply within 24hrs.
Thank you & Now pls send your kindly inquiry ! ^!^
YUEQING YUMO ELECTRIC CO.,LTD
ADD: NO.126 LIUYANG ROAD ,ZHAOYANG INDUSTRY ZONE, LIUSHI TOWN,
YUEQING CITY, ZHEJIANG PROVINCE, 325604 CHINA
TEL:0086-577-62791815 Mobile:0086-13757779011
Sky-pe:benjaminying TradeManager:yncync
