Home > Electrical & Electronics > Electric Motor > AC Motor > NEMA Standard TEFC Ball Bearing IP55 Protection Three Phase Electric Motor
NEMA Standard TEFC Ball Bearing IP55 Protection Three Phase Electric Motor
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
HALOTOP
Model Number:
265
Type:
Asynchronous Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
China Sea Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UL Approved IE2 Synchronous Speed Cast Iron Three Phase Electric MotorNegotiableMOQ: 1 Set -
IE2 Standard Synchronous Speed Cast Iron Three Phase Electric MotorNegotiableMOQ: 1 Set
-
IE2 Standard High Efficiency Cast Iron Three Phase Electric Motor T2C 280S 4NegotiableMOQ: 1 Set
-
IE3 Standard High Efficiency Cast Iron Three Phase Electric Motor T3C 160L 2NegotiableMOQ: 1 Set
-
6 Pole IE2 Standard Synchronous Speed Cast Iron Three Phase Electric MotorNegotiableMOQ: 1 Set
Brand Name
HALOTOP
Model Number
265
Type
Asynchronous Motor
Frequency
60hz
Output Power
20HP
Protect Feature
Totally Enclosed
Phase
Three-phase
Certification
CE
AC Voltage
Other, 220--660v
Place of Origin
Shanghai, China
Efficiency
Other, NEMA
Specifications
1.TEFC Three Phase Electric Motor2.Ball Bearing
3.IP55 Protection
4. Power:20HP
NEMA Standard TEFC Ball Bearing IP55 Protection Three Phase Electric Motor
| Features |
| 1.208-230/460V/60HZ or 575/60HZ |
| 2.NEMA Service Facotr 1.15/1.25 |
| 3.Continuous Duty 40°C Ambient |
| 4.TEFC (Total Enclosed Fan Cooled) |
| 5.Cast Iron Frame |
| 6.Ball Bearings |
| Applications |
| 1.Pumps |
| 2.Compressors |
| 3.Fans |
| 4.Machine Tools |
| 5.Energy Saving Application |
| 6.Other General Purpose Three Applications |
| HP | Full Load Speed (r/min) | NEMA Frame | Current | Eff. 100%FL (%) | Power Factor (Cosφ) | Full Load Torque LB-FT | Locked Rotor | Tst/Tn (Times) | Tmin/Tn (Times) | Tmax/Tn (Times) | Service Factor | |||
| Output (KW) | Inl575V (A) | Ifl575V (A) | KVA Code | Ist/In (Times) | ||||||||||
| 25 | 3550 | 256T | 15 | 5.83 | 18.35 | 90.2 | 0.91 | 29.76 | J | 8.5 | 2.3 | 2.1 | 3 | 1.15 |
| 1730 | 256T | 15 | 5.78 | 18.19 | 91 | 0.91 | 61.07 | J | 7.9 | 2.5 | 2.1 | 2.8 | 1.15 | |
| 1145 | 286T | 15 | 7.93 | 19.65 | 90.2 | 0.85 | 92.24 | J | 7.3 | 2.5 | 2 | 2.8 | 1.15 | |
