40kva Silent WEIFANG Diesel Generator Set With CE Approved
- 1000 Set / Sets per Month
- Qingdao
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | Weifang | Model Number: | 40kva |
Output Type: | AC Three Phase | Speed: | 1500/1800 rpm | Frequency: | 50/60 Hz |
Rated Power: | 40kva/32kw | Rated Voltage: | 400/230V | Rated Current: | 60A |
Product Description
40kva Silent WEIFANG Diesel Generator Set With CE Approved
-------------------Diesel Generator Main Specification----------------
Specification of genset | ||||||||
Gensets model | 40GF | |||||||
Prime power(KVA) | 50 | |||||||
Rated voltage(V) | 400 | |||||||
Rated current(A) | 72 | |||||||
Rated frequency(Hz) | 50 | |||||||
Rated Speed | 1500rpm | |||||||
Power Factor | 0.8(lagging) | |||||||
Dimensions(mm) (L×W×H) | 2440x1020x1560 | |||||||
Genset Weight(kg) | 1200 | |||||||
Specification of diesel engine | ||||||||
Engine brand | WEIFANG | |||||||
Engine model | 4BTA3.9-G2 | |||||||
Number of Cylinders | 4 | |||||||
Cylinder arrangement | Vertical in-line | |||||||
Cycle | Four stroke | |||||||
Air Intake System | Turbocharged, Water/Air DC | |||||||
Fuel System | AD type fuel pump | |||||||
Bore×Stroke (mm×mm) | 102 x 120 | |||||||
Displacement (Liter) | 3.9 | |||||||
Compression Ratio | 16.5:1 | |||||||
Speed Governor | Electronic | |||||||
Cooling System | Forced Water Cooling Cycle | |||||||
Total lubrication system capacity (L) | 16.4 | |||||||
Fuel Consumption at 100% Load (g/kwh) | 216 | |||||||
Starting Method | DC24V electrical starting | |||||||
Specification of alternator | ||||||||
Alternator brand | Chinese Stamford | |||||||
Number of Phase | 3 | |||||||
Connecting Type | 3 Phase and 4 Wires | |||||||
Number of Bearing | 1 | |||||||
Protection Grade | IP21 | |||||||
Altitude | ≤1000m | |||||||
Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire | |||||||
Insulation Class | H | |||||||
Telephone Influence Factor (TIF) | ≤50 | |||||||
THF | ≤2% | |||||||
Voltage Regulation, Steady State | ≤±1% | |||||||
Transient State Voltage | ≤-15%~+20% | |||||||
Specification of control Panel | ||||||||
The control panel is AMF control panel, with the display of voltage,current, frequency, water temperature, oil pressure. The genset with low oil pressure,high water temperature,over speed,over load protection function. | ||||||||
The features of GU620A controller: | ||||||||
GU620A is a new generation Automatic control module for single Genset, which adopts bran-new outline configuration, focus on the requirements of customers, and perfectly improves the performance of controller. It fully meets the auto control requirements of different kinds of Genset for user or special assembly factory. | ||||||||
The module also monitors and protects the engine, indicating operational status, fault conditions and metering on the front panel LCD and LED’s. |
------------------------Customers Service Center-------------------------
-------------------------------Features & Benefits---------------------------
-------------------------Soundproof & Packaging-------------------------
----------------------------------Control System------------------------------
-----------------------------Certifications Show-----------------------------
