Water-cooled Slient Diesel Generator 15kw

Name: Water-cooled Slient Diesel Generator 15kw
Brand: Ricardo
SKU: 141184614
Availability: InStock

US$ 1 - 10,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Ricardo

Model Number:

15kva

Weifang Huatian Diesel Engine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Ricardo

Model Number 15kva

Output Type AC Three Phase

Speed 1500/1800 r/min

Frequency 50/60hz

Rated Power 12KW

Rated Voltage 400/380V

Rated Current 27A

Water-cooled Slient Diesel Generator 15kw

Product Description

Technical data
Genset Model	16GF
Genset Output Power	20KVA
Rated Voltage	380/220V
Frequency	50Hz
Power Factor(COS)	0.8(lagging)
Dimension (L×W×H) (mm)	2000×900×1200
Net weight (kg)	1100
Diesel Engine
Brand	DCEC Cummins
Model	4B3.9-G2
Engine Structure	In line 4 cylinder, 4 stroke, turbocharged
Rotating Speed	1500r/min
Engine Cooling Method	Radiator for ambient temp 40^OC, belt driven cooling fan with cover
Governor System	Precise electrical governor system
Starting Method	12V DC, with Silicon commutating charging motor
Engine Filter System	Dry type air filter, fuel filter, oil filter
Displacement(L)	3.9
Compression Ratio	16.51
Bore×Stroke(mm)	102×120
100% load fuel consumption (L/h)	6.7
Lube capacity(L)	10.9
Alternator
Brand	Chinese Stamford
Excite Type	Brushless ,Self-exciting, AVR automatic voltage regulating
Connecting Type	3 Phase and 4 Wires
Steady Frequency Change	05%
No load voltage	≥95%105%
Steady voltage	≤±1%
Insulation degree	H degree
Enclosure degree	IP21
The components of the genset
(1) Diesel engine; (2) Generator; (3) Control panel; (4) Silent box
The Accessories
Wave pipe , curved pipe , muffler , accumulator and the connecting lines , shock-absorbing spacer , and data .
Control Panel
The control panel is Ordinary integrative type control panel, with the display of voltage,current, frequency, water temperature, oil pressure.
