Specifications
Function of gen sets:Display voltage, current, power, power factor, battery voltage, speed, oil pressure and water temperature
Gas Genset | Genset model | 25GFT |
Rated power (kw/kva) | 25/31.25 | |
Gas engine
| Engine model | 4102ZQ |
Rated power (kw/kva) | 33/41.25 | |
Bore*stroke (mm) | 102*115 | |
Rated speed (rpm) | 1500 | |
Starting system | Electric starting(DC24V) | |
Governing method | Electric | |
Cooling system | Closed water-cooled | |
No. of cylinder | 4cylinders in-line | |
Inspiration method | Turbo-charged | |
Gas consumption (m3/kw.h) | 0.32 | |
AC Alternator | Alternator model | Stamford/Marathon/other |
Excitation model | brushless | |
Insulation class | H | |
Protection class | IP22 | |
Factor | 0.8(Lagging) | |
Phase /wires | 3 phase 4wire | |
Gas genset | Net weight(Kg) | 550 |
Overall dimension(L*W*H)(mm) | 1650*740*1280 |
Optional accessory
Engine coolant and oil heater, alternator space heater, cooling for heat exchanger. Control system communication interface. Battery charger, fuel-water separator. daily fuel tank,ATS¶lleling system. Soundproof Canopy and Moving Trailer
