heavy duty submersible slurry pumps for sand
heavy duty submersible slurry pumps for sand feature
Size: 40 - 300 mm
Flow: 7.56 - 1490 m3/hr
Head: 4 - 55 m
Speed: 300 - 2200 rpm
The BP series pump is single stage, vertical cantilever, single and double suction pump. Liquid ends construction is the same white iron as in the other models. Bearing are grease lucricated.corrosion resistance Sump
pump.
The BPR is constructed similar to BP, except all the parts in contact with the pumpage are rubber coated, The rubber coating is used for corrosive applications.
heavy duty submersible slurry pumps for sand structure
1. Material construction optional
BP: abrasion resisting metal construction
BPR: anti-corrosive rubber construction
2. Do not need any shaft seal or sealing water
Also worked well under insufficient suction duty.
3. The type with “L” is the pump with extension shaft
It suitable to deep condition. It has guid bearing. So it more stable and used more wide. However the flushing water is necessary on the guide bearing part.
4. The agitator is available
We can assembly the agitator as requirements.
heavy duty submersible slurry pumps for sand curve
Technical Parameters of heavy duty submersible slurry pumps for sand
Type | Outlet Diameter mm | Speed n r/min | Water performance | motor Power kw | Impeller Diameter mm | ||
Capacity Q (m3/h) | Head H (m) | Efficiency (%) | |||||
40PV- BP(R) | 40 | 1000-2000 | 17-43.2 | 4-28.5 | 40 | 15 | 188 |
65QV- BP(R) | 65 | 700-1500 | 18-114 | 5-31.5 | 60 | 30 | 280 |
100RQV- BP(R) | 100 | 500-1200 | 54-289 | 5-36 | 62 | 75 | 370 |
150SV- BP(R) | 150 | 500-1000 | 108-479 | 8.5-40 | 52 | 110 | 450 |
200SV- BP(R) | 200 | 400-850 | 189-891 | 6.5-37 | 64 | 110 | 520 |
250TV- BP(R) | 250 | 400-750 | 261-1089 | 7-33.5 | 60 | 200 | 575 |
300TV- BP(R) | 300 | 350-700 | 288-1267 | 6-33 | 50 | 200 | 610 |
heavy duty submersible slurry pumps for sand spare parts
With large quantity of spare parts in stock, our delivery time is generally very short.
heavy duty submersible slurry pumps for sand application
This pump is suitable for metallurgy, mining, coal, power plants, building materials and general industrial applications that convey abrasive and high-concentration slurry.
This pump has been used very successfully for ash removal in power plants.
In the mine site pump station
Drainage slurry working condition
heavy duty submersible slurry pumps for sand packing and shipping
Shijiazhuang An Pump Machinery Co., Ltd is a professional manufacturer of slurry pumps, sewage pumps, clean water pumps, chemical pumps, fire pumps, irrigation pumps; An Pump Machinery company has its own Kingda type selection & design, research and development team, assure to provide you efficient, energy saving slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps type design, use and maintenance program.
Some of our clients show:
Our Services
1. Offer Large capacity sea water pump solutions
2. Selection
3. OEM available
4. ODM available
5. Design
6. Installation
7. Maintenance
Learn more , please contact us directly.
