Mine Processing Gravel Sand Pump

Mine Processing Gravel Sand Pump thumbnail-1
Mine Processing Gravel Sand Pump thumbnail-2
Mine Processing Gravel Sand Pump photo-1
Mine Processing Gravel Sand Pump photo-2
US$ 300 - 180,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
An Pump
Model Number:
AMG
Contact Supplier Request Quote Chat Now
Shijiazhuang An Pump Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin or other seaports in China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name An Pump
Model Number AMG
Theory Centrifugal Pump
Structure Single-stage Pump
Usage Other, transporting abrasive or / and corrosive slurry in mining, metallurgy,
Power Other, Electric, 15 - 560 kw
Standard or Nonstandard Standard
Fuel Other, diesel and gasoline
Pressure Other, standard
Application Other, slurry liquid, slage,sludge, sewage, solid liquid etc
Product Description

 AM/AMR series is horizontal, cantilevered centrifugal slurry pump, with reasonable construction, reliable operation, long service life. It is widely used in transporting abrasive or / and corrosive slurry in mining, metallurgy, electric power, coal, chemicals, building, etc. Especially well accepted by coal / chrome washing plant, mineral processing plant, power plant etc.



Mine processing gravel sand pump



Design Features



• Bearing assembly – A large diameter shaft with short overhang minimizes deflection and contributes to long bearing life. Only four  through bolts are required to hold the cartridge type housing in the  frame.

• Liners – Easily replaceable liners are bolted, not glued, to the casing for positive attachment and ease of maintenance. Hard metal liners are completely interchangeable with pressure molded  elastomers. Elastomer seal rings back all liner joints.

• Casing – Casing halves of cast or ductile iron with external reinforcing ribs provide high operating pressure capabilities and an extra measure of safety.

• Impeller – Front and rear shrouds have pump out vanes that reduce recirculation and seal contamination. Hard metal and molded elastomer impellers are completely interchangeable. Cast  in impeller threads require no inserts or nuts. High efficiency and high head designs are also available.

• Throat bush – Wear is reduced and maintenance simplified by the use of tapered mating faces to allow positive accurate alignment during assembly and simple removal.

• One-piece frame – A very robust one-piece frame cradles the cartridge type bearing and shaft assembly. An external impeller adjustment mechanism is provided below the bearing housing for

easy adjustment of impeller clearance.





AM/AMR Slurry Pump Structure





Mine processing gravel sand pump



Metal liner

Rubber liner

1

Volute liner

1

Frame plate

2

Frame plate

2

Expeller ring

3

Frame plate liner insert

3

Gland assembly

4

Cover plate

4

Shaft sleeve

5

Throat bush

5

Expeller

6

Impeller

6

Frame plate liner

7

Expeller ring

7

Impeller

8

Shaft sleeve

8

Cover plate liner

9

Expeller

9

Cover plate

10

Bearing assembly

Note: Slurry pumps have Throat Bush from 4"





AM,AMR Slurry Pump Performance Data



Model

Max Power

(kw)

Material

Clear water performance

Liner

Impeller

Capacity Q

(m3/h)

Head

H ( m)

Speed

n (rpm)

1.5/1B-AM

15

M

M

12.6~28.8

6~68

1200~3800

RU

RU

10.8~25.2

7~52

1400~3400

1.5/1B-AMH

30

M

M

16.2~34.2

25~92

1400~2200

2/1.5B-AM

15

M

M

32.4~72

6~58

1200~3200

RU

RU

25.2~54

5.5~41

1000~2600

3/2C-AM

30

M

M

39.6~86.4

12~64

1300~2700

RU

RU

36~75.6

13~39

1300~2100

4/3C-AM

30

M

M

86.4~198

9~52

1000~2200

4/3D-AM

60

4/3C-AM

30

RU

RU

79.2~180

5~34.5

800~1800

4/3D-AM

60

4/3E-AMH

120

M

M

126~252

12~97

600~1400

6/4D-AM

60

M

M

162~360

12~56

800~1550

6/4E-AM

120

6/4D-AM

60

RU

RU

144~324

12~45

800~1350

6/4E-AM

120

6/4F-AMH

260

M

M

100~414

34~98

600~1000

8/6E-AM

120

M

M

360~828

10~61

500~1140

8/6E-AM

120

RU

RU

324~720

7~49

400~1000

10/8ST-AM

560

M

M

612~1368

11~61

400~850

RU

RU

540~1188

12~50

400~750

10/8E-MM

120

M

M

666~1440

14~60

600~1100

10/8E-MM

120

RU

RU

540~1188

10~42

500~900

12/10ST-AM

560

M

M

936~1980

7~68

300~800

M

M

720~1620

7~45

300~650

14/12ST-AM

560

M

M

1260~2772

13~63

300~600

RU

RU

1152~2520

13~44

300~500

16/14ST-AM

560

M

M

1368~3060

11~63

250~550

16/14TU-AM

1200

18/16ST-AM

560

M

M

2160~5040

8~66

200~500

18/16TU-AM

1200

20/18TU-AM

1200

M

M

2520~5400

13~57

200~400







AM, AMR Slurry Pump Performance Curve



Mine processing gravel sand pump







Pump Application



Pump Applications



Chemical Process

Heavy Minerals

Paper and Pulp

Mill Discharge

Sugar Beet

Slag Granulation

Bottom Boiler and Fly Ash

Cyclone Feed

Power Utilities





Packaging & Shipping



 AM, AMR Slurry Pump Package and Shipping Term





Mine processing gravel sand pump



 Mine processing gravel sand pump







Company Introduction
Shijiazhuang An Pump Machinery Co., Ltd is a professional manufacturer of slurry pumps, sewage pumps, clean water pumps, chemical pumps, fire pumps, irrigation pumps; An Pump Machinery company has its own Kingda type selection & design, research and development team, assure to provide you efficient, energy saving slurry pumps, sewage pump, water pump, chemical pumps, fire pumps, irrigation pumps type design, use and maintenance program.

An Pump Machinery products slurry pumps, sewage pump,water pump,chemical ;pumps,fire pumps, irrigation pumps and other products are exported to over 90 countries around the world. The application covers many fields, such as dressing ship, tailings transportation, mining pumps, steel & power desulphurization, boiler feed water, construction, irrigation, water conservancy facilities, sewage treatment.
