Horizontal metallurgical mill pulp slurry pump
- 500 Set / Sets per Month
- Tianjin Port
- T/T L/C D/P D/A Credit Card
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Hebei, China | Brand Name: | An Pump | Model Number: | AM, AMH |
Theory: | Centrifugal Pump | Structure: | Single-stage Pump | Usage: | Other, mill slurry pump |
Power: | Electric | Standard or Nonstandard: | Standard | Fuel: | Other, electric oulp pump |
Pressure: | Other, high pressure mill pulp pump | Application: | Other, Heavy Duty pulp slurry pump |
Product Description
Horizontal metallurgical mill pulp slurry pump
Description:AM,AMH series Horizontal heavy duty paper pulp pumps are cantilever horizontal centrifugal pump.
They are widely used in industry of paper pulp plant, mining, electrical power, metallurgy, coal, environmental, etc for transportation of abrasive solid slurry, such as metallurgical mill pulp conveying, hydraulic ash power plant desulphurization, coal washery coal slurry and heavy medium conveying, river dredging ect; in chemical industry, they can be used for transportation of corrosive crystallization slurry. Mud pump, impurity pump, dredge pump and desilting pump are all belong to category of slurry pump. They can be used in series. Our product including AM, AMH, AL horizontal slurry pump, BP, BPR submersible slurry pump, WN dredging pump, AG, AGH gravel pump and AMR rubber abrasion & corrosion resistance slurry pumps etc. Head range 6-120m, flowrate 12m3/h-3400m3/h. Material are vary from corrosion and abrasion degree, high chrome abrosion& corrosion resistance alloy Cr27MoNi, Cr30MoNi are optional.
The advantanges are as follows:
1) High concentration, volume concentration reach to 60%, weight concentration reach to 70%;
2) Comprehensive performance is good, high head: long distance and high head transportion, single set head can reach to max 120m, and can be used in series to satisfy much higher head requirements;
3) High flowrate capacity: can be reached 3400m3/h;
4) Good passing ability:gravel pump max passing particles size is 380mm;
5) Diameter size:outlet size from 1” to 22”
6) Widely application: all slurry, mud and bad corrosive medium can be transported, widely used in industry of mining, electrical power, metallurgy,coal, construction etc.
7) High corrosion, abrasion resistance widely material optional: metal flow parts including:A05 (Cr27Mo),A33(Cr30MoNi)A49(Cr30MoNiCu)and rubber material etc. PH value 1.0-14.
8) Our company passed ISO certificate and all of our pumps pass CE certificate, comply with international standards.
9) Driving engine of motor and diesel are available;
10) Kinds of driving method satisfy different space need on site: CR, CZ, CV, ZV;
11) Energy saving and cost reducing: pump itself water conservancy design advanced and mature. In the mode of traditional direct start increasing soft start and frequency start methods, it make sure energy saving and protection devices; Adjust the speed by soft connection mode in order to achieve the maximum utilization and tower results of work.
12) Easy operation, lower noise.
What is the Horizontal metallurgical mill pulp slurry pump Advantage
over 20 years' experience in pumps
Wear resistant material
Specialized Test Equipment
Anti-rust treatment casting
What is the Horizontal metallurgical mill pulp slurry pump Applications
paper pulp plant
regrind cyclone feed slurry Pump are designed for handling abrasive, high density slurries in the metallurgical, mining, coal, power, building material and other industrial departments.
What is the Guarantee and Service
1 year guarantee of whole machine set, except the flow parts
24hours *7 days service is available
Calling or door to door service
User manual and maintenance instruction is available
- Standard wooden cases package, if special requirements, should be inform in advance;
- Shipping by sea, by air, by train and truck all available;
- Delivery date: vary from 5-30days according to different model and quantity.
Shijiazhuang An Pump Machinery Co., Ltd is a professional manufacturer of slurry pumps, sewage pumps, clean water pumps, chemical pumps, fire pumps, irrigation pumps; An pump machinery company has its own strong type selection & design, research and development team, assure to provide you efficient, energy saving pumps type design, use and maintenance program
Q1. Are you a manufacturer?
Yes, we have been in centrifugal pumps manufacturing and marketing industry over 32 years.
Q2. What markets do your pumps export to?
Europe, North & South America, SouthEast Asia, Africa, Oceanica, Middle East countries. Our overseas agent in Italy, Russia, Canada, France, America, Middle East, Asia and Africa are gradually improving.
Q3. What information should I let you know if I want to get a quotation?
Please let us know the pump capacity, head, medium, operation situation, quantity, etc. As much as your provide, the precision
and accurate model selection.
Q4. Is it available to print our own brand on the pump?
Totally acceptable as international rules.
Q5. How can I get the price of your pump?
You can connect with us through any of the following contact information. Our personalized service person will respond you within 24 hours.
