Home > Products > Medium pumped > QS Horizontal split case centrifugal irrigation Water Pump
QS Horizontal split case centrifugal irrigation Water Pump
- 500 Set / Sets per Month
- Tianjin China
- T/T L/C D/P D/A Credit Card PayPal
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Hebei, China | Brand Name: | An Pump | Model Number: | QS Horizontal split case centrifugal irrigation Water Pump |
Theory: | Other, Centrifugal volute vane pump | Structure: | Other, Single Stage split case Suction pump | Usage: | Other, Transfer Pump, jet Pump, process pumps |
Power: | Other, Electric High Effluent Pump and easy for pump repair | Standard or Nonstandard: | Other, Standard Split case irrigation Pump parts Stocking | Fuel: | Other, Low cost diesel engine driven dewatering pump |
Pressure: | Other, High Pressure Split casing Pump | Application: | Other, Irrigation Pumps, Dewatering Pumps, Sewage Pumps, coolant Pump |
Product Description
QS Horizontal split case centrifugal irrigation Water pump
The QS horizontal Split case centrifugal irrigation pumps is the horizontal double suction pump.
The casing is axially split, the casing is axially split, which permits removal of the complete rotor without moving either piping or motor.Pumps generating high heads have double volutes to reduce radial forces.
Replaceable wear ring protect the casing at the impeller running clearances. Vertical or horizontal, soft packing or mechanical seal, grease or oil lubrication bearing is optional according your working conditon, and so as electric motor or diesel engine driver.
Horizontal split case centrifugal irrigation pump Application
The split casing pump is widely used in water supply or drainager projection in different industries, such as metallurgy, power station, spinning and weaving, chemical, printing, dyeing, ceramics, rubber, heating, afterheating use, air conditioner, farm irrigtion and drainage, and so on...
Material of Horizontal split case centrifugal irrigation pump
Casing | Cast Iron and Ductile Iron standard; optional Stainless Steel |
Impeller | Bronze standard, optional Brass, Cast Iron, and Stainless Steel |
Split casing pump Shaft | AISI420 standard, optional AISI304 & AISI316 |
General Description of Horizontal split case centrifugal irrigation pump
Type QS,QSH pumps are single stage, double suction with horizontally split casings.
Type QS ,QSH pumps are adoptable in factories, mines, water works, power stations, hydraulic engineering, irrigation or drainage services in agriculture, etc.
Constructure drawing of Horizontal split case centrifugal irrigation pump
Horizontal split case centrifugal irrigation pump
performance parameters
Model | Flow rate (m3/hr) | Head (m) | Speed (rpm) | Power (kw) | Eff (%) |
QS150 | 110~220 | 35~84 | 2900 | 30~55 | 67~80 |
QS200 | 160~351 | 31~100 | 2900 | 37~110 | 67~85 |
QS250 | 324~612 | 8.6~71 | 1450 | 22~132 | 72~86 |
QS300 | 504~972 | 8~98 | 1450 | 30~300 | 70~84 |
QS350 | 745~1663 | 10~140 | 1450 | 55~680 | 70~88 |
QS400 | 900~1620 | 32~98 | 980~1480 | 155~500 | 71.5~84 |
QS500 | 1150~2450 | 10.6~108 | 740~970 | 110~800 | 70~89 |
QS600 | 2304~4000 | 13~80 | 730~970 | 185~900 | 70~91 |
QS700 | 2111~4896 | 39.5~99.5 | 740~980 | 560~1250 | 72~92 |
QS800 | 3960~7200 | 23.5~84 | 600~740 | 450~1600 | 77~92 |
QS1000 | 6000~9900 | 32~52 | 600~990 | 1250 | 79~87 |
QS1200 | 5832~14400 | 6~95.7 | 500~745 | 710~3450 | 80~90 |
An Pump Machinery is your Best Horizontal split case centrifugal irrigation pump Manufacturer
An Pump Machinery Co. ,Ltd is the Horizontal split case centrifugal irrigation pump manufacturer with 50+ years experienced
Our pumps export to over 90 countries all over the world in mining, power plant, dredging and dredge, hydraulic, irrigation, pulp transfer, chemical, construction, sea water and oil & gas transfer etc. click to more...
An Pump Machinery is your ISO certificated Horizontal split case centrifugal irrigation pump Manufacturer
An Pump Machinery is also CE cerficated Horizontal split case centrifugal irrigation pump Manufacturer
Standard wooden case packing of Horizontal split case centrifugal irrigation pump
An Pump Machinery Company to Customers:
1)Quality first. We guaranteed every part of the pump must be inspected closely
2)We can help you select suitable pump model according to your working condition and requirements.
3)We can design the related base or engine for your pumps.
4)Fast delivery time, large quantity of spare parts in stock.
End suction pump | Split casing pump | Multistage pump |
