Horizontal Centrifugal End Suction Fruit Juice Pump
♦♦♦♦ OVERVIEW ♦♦♦♦
Overview of Horizontal Centrifugal End Suction Fruit Juice Pump
Horizotal centrifugal back pull out end suction massecuite pump is a kind of horizontal centrifugal single stage single suction back pull out pump.
End suction pumps are base frame mounted, general purpose, centrifugal pumps.
Heavy duty construction makes the pump popular in a wide range of commercial and industrial applications.
The pump is generally manufactured with cast iron casings and cast iron, stainless steel, plastic, or brass impellers, making them reliable, long lasting and easy to maintain.
♦♦♦♦ MATERIAL ♦♦♦♦
Material of Horizontal Centrifugal End Suction Fruit Juice Pump
Casing |
Cast Iron and Ductile Iron standard; optional Stainless Steel |
Impeller |
Brass standard, optional Cast Iron & Stainless Steel |
Shaft |
AISI420 standard, optional AISI304 & AISI316 |
♦♦♦♦ APPLICATION ♦♦♦♦
Application about Horizontal Centrifugal End Suction Fruit Juice Pump
Pump is used to delivery clean water, pulp, juice or liquid similar water in the properties of phusical and chemical.
It is widely used in liquid supply or drainager projection in different industries, such as metallurgy, power station, spinning and weaving, chemical, printing, dyeing, ceramics, rubber, heating, afterheating use, air conditioner, farm irrigtion and drainage, and so on...
♦♦♦♦ DIFFERENCES ♦♦♦♦
Difference between QI and QIR type Horizontal Centrifugal End Suction Fruit Juice Pump
QI: End suction fruit juicing pump delivery water not more than 80 Celsius degree.
QIR series is hot temperature pump, delivery water not more than 150 celsius degree.
Special can full demand in 300 Celsius degree.
♦♦♦♦ PERFORMANCE TABLE ♦♦♦♦
Performance data of Horizontal Centrifugal End Suction Fruit Juice Pump
♦♦♦♦ PERFORMANCE CURVE ♦♦♦♦
Performance curve of Horizontal Centrifugal End Suction Fruit Juice Pump
♦♦♦♦ CONSTRUCTION ♦♦♦♦
Structure of Horizontal Centrifugal End Suction Fruit Juice Pump
♦♦♦♦ PACKAGING & SHIPPING ♦♦♦♦
Packaging and shipping for Horizontal Centrifugal End Suction Fruit Juice Pump
♦♦♦♦ FAQ ♦♦♦♦
FAQ about Horizontal Centrifugal End Suction Fruit Juice Pump
Horizontal Centrifugal End Suction Fruit Juice Pump 's pipeline Configuration Considerations
The size of the pipe diameter’s choose need to consider the system resistance, slurry flow rate and other comprehensive settlement of the critical factors. Suction pipe should be short and straight. In the suction of the slurry pump, the best way is install a straight pipe what have some size with the inlet pipe’s diameter, its length should not be less than three times of the inlet diameter. Generally speaking,the suction pipe flow is 1.5-3.0m / s, depending on the flow rate of the slurry.
When using high slurry pump suction piping’s arrangement should avoid the residual air, recommend adopt the level reducer pipe.
The control valve should be located in the massecuite pump outlet pipe when use the flow control valves,it is not be allowed install in the inlet pipe, in order to avoid cavitation.
♦♦♦♦ APPLICATION ♦♦♦♦
♦♦♦♦ CERTIFICATION ♦♦♦♦
Certification for Horizontal Centrifugal End Suction Fruit Juice Pump
♦♦♦♦ OUR HISTORY ♦♦♦♦
♦♦♦♦ ORGANIZATIONAL STRUCTURE ♦♦♦♦
♦♦♦♦ CONTACT US ♦♦♦♦
Contact AN PUMP for Horizontal Centrifugal End Suction Fruit Juice Pump
