Hot Water Circulation Pump farm irrigation lift pump
- 350 Set / Sets per Month
- Tianjin China
- T/T Credit Card PayPal
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Hebei, China | Brand Name: | An Pump | Model Number: | QI |
Theory: | Centrifugal Pump | Structure: | Single-stage Pump | Usage: | Other, end suction boiler pump with electric motor |
Power: | Electric | Standard or Nonstandard: | Standard | Fuel: | Other, motor or diesel or gasoline |
Pressure: | Other, standard | Application: | Other, Water Supply Hot Water Circulation |
Product Description
Hot Water Circulation Pump farm irrigation lift pump
Description - Hot Water Circulation Pump farm irrigation lift pump
QI model pump is single-stage end-suction(axial suction) cantilever type centrifugal pump,
which is used to transport corrosive liquid with viscosity similar to water and without solid
particles. The marked and rated performances and dimensions adopt ISO2858 international standard.
It has such characteristics as wide range of performance, high efficiency, high mechanical,
chemical and physical level and convenient maintenance etc. It is energy saving type product
recommended by the nation with its efficiency being 5% greater than that of other similar model pump.
The temperature of transported media of QI model pump is -20 – 105 C deg . Through adopting
cooling method, it can transport media with higher temperature if necessary, and is applied to
transport various corrosive media or media in which pollution is forbidden similar to water in such
industries as chemical industry, petroleum, metallurgy , electric power, paper making, food,
pharmacy and synthetic fiber etc.
Application - Hot Water Circulation Pump farm irrigation lift pump
1.Constructional engineering: Clear water transportion,pressurization system,air
condition water,circulation system,fire extinguishing system,swimming pool and water circulation system.
2.Industry : circulating cooling system ,process water for papermaking and paper pulp,steel production,shipbuilding,sea trasportion,and other mafacturing industry
3.Mining industry : water supply,mine drainage,generating station,ect.
4.Other: municipal water supply,agricultural irrigation,and some others.
Structure -Hot Water Circulation Pump farm irrigation lift pump
1 | Pump casing | 4 | Impeller nut | 7 | Mid bracket |
2 | Impeller | 5 | Pump cover | 8 | Shaft |
3 | Seal ring | 6 | Seal part | 9 | Hanging stand |
1.QI model pumps are the series of products designed according to ISO international standards
in all industries in China. It is mainly composed of pump body, impellers, seal rings, impeller nuts,
pump cover, seal parts, intermediate support, spindle, suspended parts and so on.
2.Structural features : the pump cover is fixed on the intermediate support, and the pump cover
is clamped in the middle by coupling between pump body and intermediate support. On the pump
body, water is input axially and output radially. Support feet can be fixed on t he bas e directly.
The suspended parts are fixed onto the intermediate support through the rabbet, and are
supported onto the base by suspended frame
3. Rotation direction: the pump is driven by motor directly through a prolonged coupling, seen from
the side of the motor, it rotates clockwise.
4. Spindle seal patterns: spindle seal patterns o f pump are of two types such as stuffing seal and
mechanical seal. The stuffing seal is that on stuffing casein pump cover , with software stuffing for
sealing, input water of a certain pressure into the stuffing case, for cooling, lubrication and cleaning
on seal; mechanical seal is of two types such as single-surface mechanical seal and double-surface mechanical seal, input water of a certain pressure into the seal chamber, for washing and
cooling on the abrased surfaces.
Seal patterns of pump are of stuffing seal or mechanical seal, according to users' requirements, in
a same time, seal chamber sizes and shaft gland patterns of other structures according to ISO3069
as required, are allowed, such as mechanical seals of corrugated pipes, assistant impeller seals and so on.
Performance - Hot Water Circulation Pump farm irrigation lift pump
You will get products and service advantages
*About 30 years Design, produce and service experience.
*Price is suitable. We are directly factory, own finished foundry model, cost only including original materials fee, machinery fee, worker fee.
*Quality, our materials used high chrome, reached above 27%, 28%, wear resistant and corrosion resistant , pump use life longer. High products quality, All our pump material is wear-resistant high Chrome alloy or nature rubber. All our products Pass ISO9001:2008 and CE certificate
*After sale service, we can offer 2 years quality guarantee, also have a very strong technical support department and special after sale service department. When you have any need future, we can sent you professional technical man to Russian help you. We also have one of group high quality technicians who can help you solve any question during the process
*When received your order, we have very professional manufacture process and supervision process. For you, i also will to plant supervise manufacture and take photo for you per day in person. So can keep you do not worry.
*After finish manufacture, we will test each pump. take a video and make a testing report for you. If available, you also can to our factory to supervise testing in person.
*Fast Delivery: For pump standard parts, we have large stock, so we can arrange delivery very soon
*Rich export Experience. we had export USA, Germany,Canada , Australian and so on developed country and South Africa, Southeast Asia,south America, North America, Russia and so on many country. our products get high reputation at home and abroad.
