Specifications
1.ISO9001:20082. measurement precision: + 2 mm
3.Detection distance: 0.1 ~ 150mm
4.Protection grade:IP65
Product overview
The laser range sensor using laser to measure the phase comparison method, can be measured without contact with the surface or the reflective target surface.
The product structure design is reasonable, with adjustable mounting bracket, purge the lens unit, air cooling device, suitable for industrial applications, especially for high-precision, non-direct contact applications, such as crane operation locate and metallurgical production line control and so on.
Product features
- Mm level measurement accuracy
- Continuous detection of a moving object
- For high temperature/dusty environment
- Precision-heavy-no need to reflect board
- With regional test ,control system and numeration function
Product type
ZYT-0040-1 10Hz RS232/RS422
ZYT-0040-2 50Hz RS232/RS422
ZYT-405 Detection and control zone distance; output switch or level signal
Technical target
- Accuracy: ± 2mm
- Resolution rate: 0.1mm
- Repeatability: 0.5mm
- Measuring distance: 0.1 ~ 30m of any surface
30 ~ 150m need to add reflectors - Supply voltage: 10 ~ 24VDC
- Power consumption: 1W
- Laser Level: 650nm visible red
- 2 levels of security laser≤ 1mW
- Switch capacity: alarm output
- Simulation volume: 4 ~ 20Ma
- Protection class: IP65
- Dimensions: 195 × 55 × 115mm
- Housing: Aluminum
- Life: more than 50,000 h
- Weight: 2.0kg
