Help CenterLaser Position Detector
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
AIGER
Model Number:
ZYT-CJ-200
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin&Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Beijing, China
Brand Name
AIGER
Model Number
ZYT-CJ-200
Usage
Other, laser distance
Specifications
1.Range optional2. measurement precision: + 2 mm
3.Detection distance: 0.1 ~ 150mm
4.Protection grade:IP65
Product overview
The laser position detector using laser to measure the phase comparison method, can be measured without contact with the surface or the reflective target surface.
The product structure design is reasonable, with adjustable mounting bracket, purge the lens unit, air cooling device, suitable for industrial applications, especially for high-precision, non-direct contact applications, such as crane operation locate and metallurgical production line control and so on.
Product features
- Mm level measurement accuracy
- Continuous detection of a moving object
- For high temperature/dusty environment
- Precision-heavy-no need to reflect board
- With regional test ,control system and numeration function
Product type
ZYT-CJ-200
Technical target
- Accuracy: ± 2mm
- Resolution rate: 0.1mm
- Repeatability: 0.5mm
- Measuring distance: 0.1 ~ 30m of any surface
30 ~ 150m need to add reflectors - Supply voltage: 10 ~ 24VDC
- Power consumption: 1W
- Laser Level: 650nm visible red
- 2 levels of security laser≤ 1mW
- Switch capacity: alarm output
- Simulation volume: 4 ~ 20Ma
- Protection class: IP65
- Dimensions: 195 × 55 × 115mm
- Housing: Aluminum
- Life: more than 50,000 h
- Weight: 2.0kg
Schematic diagram
