1.Function and characteristics:
1.1 measurement function : measurement positive and reverse power.cumulation
in total power
1.2 Adopt (5+1) or (6+1) register display
1.3 Power pulse indicator,power indicator
1.4 35mm DIN Standard installation or Board before installation
1.5 Pulse output
1.6 Adopt good quality electricity part,good overload ability,long-term work
does not need adjustments
2.Parameters and specification:
Rated voltage: 110V 120V 220V 230V 240V +20%
Frequency: 50HZ or 60HZ
Rated current: 1.5(6)A 5(30)A 10(60)A 20(80)A
Accuracy: class 1.0
Voltage circuit consumption : ≤1.0W 5VA
Current circuit consumption: ≤1VA(Ib)
Normal working temperature: -15°C~+55°C
Storage transport temperature: -25°C~+70°C
Environmental temperature: ≤ 85%
Using life: more than 10 years
Shape dimension: 75*88*73.5mm
Weight: about 350g
