Specifications
1.china spectrum analyser2.Warranty:12 month
3.Delivery time: About 7days after received your payment
4.MOQ:1 pc
A & E Lab
A & E Lab Hot Selling are include: UV VIS Spectrophotometer, Visible Spectrophotometer, Flame Photometer, PCR-Cycler, Blocker Heater, Hotplate, Stirrer, Stirrer Hotplate, Rotory Mixer, Tube Roller Mixer, 3D Rocker, See-Saw Rocker, Vortex Mixer, Orbital Shaker, Cold Keeper, Melting Point Device, Shaker Incubator, etc.
Welcome to inquire us!
The information of our instruments:
Warranty : 1 year / 3 years / 2 years
Certifications: CE&ISO
Delivery time: Within 10 days after received your payment
MOQ: 1 unit
Payment term: T/T advance, paypal, western union, Moneygram
Cooperation type: Distribute / Neutral packing / OEM / ODM.
Key Features:
* Double beam spectrophotometer with highly stable optics.
* Extremely versatile with full functionality
from 190 to 1100nm.
* Variable spectral bandwidth 0.5, 1, 2, 4,5nm.
* 2 or 8 cell holder available.
* 6 inches LCD display & integrated user interface.
* USB port for data storage.
* ISO/CE Certificate passed.
* A & E Lab PC software included as standard.
* Extensive range of accessories available.
Applications:
AE-S90 Series are wide screen double beam spectrophotometer. Its integrated design assures long term stability and
durability. The highly stable optics and two detectors measure the sample and reference simultaneously optimising
measurement accuracy. It has measurement modes for photometrics, concentration, multi-wavelength, spectrum
scanning, kinetics, quantitation, DNA and protein analysis. The PC software is supplied as standard and offers additional
functionality with preloaded methods for DNA and protein analysis, as well as extensive post-measurement tools,
unlimited results saving and easy export of data.
The precisely aligned detector and quality deuterium and halogen lamps enhance the precision across the uv/vis spectrum starting
from 190nm and into the near-infrared 1100nm. It is ideal for quality control, general research, pharmaceutical,
biochemical and clinical laboratory applications.
Ordering Information:
Order Code | Description |
AE-S90-MD | Large screen, double beam, 2 single cell holder, Bandwith: 0.5/1.0/2.0/4.0/5.0nm, with PC software. |
AE-S90-1D | Large screen, double beam, 2 single cell holder, Bandwith: 1nm, with PC software. |
AE-S90-2D | Large screen, double beam, 2 single cell holder, Bandwith: 1.8nm, with PC software. |
Technical Specifications:
Wavelength | Photometric | ||
Wavelength Range | 190-1100nm | Accuracy | ±0.3%T |
Wavelength Accuracy | ±0.3nm | Photometric Repeatability | 0.2%T |
Wavelength Repeatability | 0.2nm | Photometric Display Range | -0.3-3A,0-200%T,0-9999C |
Bandwith | 1nm/1.8nm/0.5,1,2,4,5nm | Stability | ± 0.001A/h @ 500nm |
Others | Baseline Flatness | ±0.001A | |
Data Output Port | USB | Noise | ±0.001A |
Printer Port | Parallel Port | Stray Light | ≤0.05%T @220nm, 360nm |
Optical System | Double Beam (1200 lines/mm grating) | ||
Display | LCD (320x240 Dots) | ||
Lamps | Deuterium & Tungsten Halogen Lamp | ||
Detector | Silicon Photodiode | ||
Software | UV PC Software | ||
Power Supply | AC 220V/50Hz, 110V/60Hz. | ||
Packing Size & Weight | 860x660x465mm & 35kg | ||
