Product Description
AE-PM200 Polarizing Microscope
Technical Specifications:
| Item | Specifications |
AE-PM200 |
| Eyepiece | WF 10x-18mm |
* |
WF 10×-18mm (Reticule 0.1mm) |
* |
|
Non-stress Infinity Plan Objective |
4x |
* |
10x |
* | |
20x (S) |
* | |
40x (S) |
* | |
60x (S) |
# | |
Seidentopf Binocular Head |
Inclined 30°, Rotatable 360°, Interpupilary Distance: 50-75mm |
* |
Seidentopf Trinocular Head |
Inclined 30°, Rotatable 360°, Interpupilary Distance: 50-75mm. Light Distribution 20:80 |
# |
Nosepiece |
Quadplex, Center adjustable |
* |
Analyzer Unit |
0-90°,It can be moved out of the optical path for single polarizing observe. |
* |
Bertrand Lens |
It can be moved out of the optical path. |
* |
λ Slip |
First Class Red |
* |
1/4λ Slip |
|
* |
Quartz Wedge |
(Ⅰ- IV Class) | # |
Revolving Round Stage |
Rotatable 360°, Division 1°, Vernier division 6°,can be locked. |
* |
Polarizing Attached Mechanical Stage |
# | |
Condenser |
Abbe N.A. 1.25 Non-stress |
* |
Polarizing Unit |
It can be moved out of the optical path. |
* |
Illumination |
6V/20W Halogen Lamp |
* |
6V/30W Halogen Lamp |
# | |
3W-LED Lamp |
# | |
| Filter | Blue(Built in) |
* |
Amber |
# | |
Green |
# | |
Neutral |
# | |
| C-mount | 1×,0.47×(Focus adjustable) |
# |
Note: " * "In Table Is Standard outfits, " # " Is Optional Accessories.
Packing Size: 570mm×275mm×450mm
Gross Weight: 8.6 kgs
Net Weight: 7.5 kgs
More Detailed Information & Packing & Shipping
Packing: Standard Export package
Shipping: By Sea, Air or Air-express
Delivery time: within 10-15 days after received the payment.
Warranty: 1 year
