Home > Instruments & Meters > Analysis Instrument > Other Analysis Instruments > Lab Microwave Digestion MWD-S01
US$ 5,000 - 10,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
A&E Lab
Model Number:
MWD-S01
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Guangzhou Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
18L/23L Class B Vertical Autoclave Steam Sterilizer Autoclave PriceUS$ 600 - 1,200MOQ: 1 Piece -
18L/23L Class N Vertical Autoclave Steam Sterilizer Autoclave Sterilization MachineUS$ 1,120 - 1,120MOQ: 1 Piece
-
18L/23L Class B Vertical Autoclave Steam Sterilizer MachineUS$ 1,120 - 1,120MOQ: 1 Piece
-
18L/23L Vertical Autoclave Steam Sterilizer Autoclave Sterilization MachineUS$ 1,120 - 1,120MOQ: 1 Piece
-
Class N Series Autoclave for SaleUS$ 1,300 - 1,300MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
A&E Lab
Model Number
MWD-S01
Company Information
A & E LabHot Selling are include: UV VIS Spectrophotometer, Visible Spectrophotometer, Flame Photometer, PCR-Cycler, Blocker Heater,Hotplate, Stirrer, Stirrer Hotplate, Rotory Mixer, Tube Roller Mixer, 3D Rocker,See-Saw Rocker, Vortex Mixer, Shaker Incubator, etc.
Welcome to inquire us!
Product Description
Product introduction:
Microwave digestion, as a high efficient sample preparation method, has advantages of fast heating, uniform heating performance, minimal reagent use, lower reagent blank, energy Saving and high efficiency. It keeps sample for volatile element analysis testing .It is widely used in food, textile, Geology, metallurgy, coal, biological medicine, petroleum chemistry, environment monitoring, sewage treatment, battery manufacturing fields.
Features:
1.Set standard curves according to pressure and time and display on the touch-screen
2.Test Pressure without, real-time monitoring and display pressure of the digestion vessel
3.Set digestion pressure and time according to different requirements
4.Set corresponding pressure protection in accordance with different conditions
5.Users can set parameters in various functions according to their own requirements
6.Different models can realize: high pressure digestion, multi-vessel closed digestion, confined organic synthesis
7.Can edit, and store 255 digestion programs; each method can set up 10 digestion procedure; Can set relative parameters (pressure, time and microwave power) according to user’s requirements.
8.Realize 360°rotation of digestion vessel to solve uniformity problem.
9.High- frequency and resonance type programming; Users can set 0-1000W according to their requirements.
10.Automatic calibration for different parameters and basic troubleshooting function
Technical Specifications:
Model | MWD-S01 | MWD-D01 | |
Pressure Control | Full Scanning | ||
Temperature Control | No | Full Scanning | |
Vessel Volume | 60ml | ||
Pressure Testing | Non-Touching | ||
Temperature Testing | No | Non-Touching | |
Digestion Vessel | 6 | ||
Vessel Material | Inner Vessel: Imported TFM; Outer Vessel: Imported PEEK+ glass fiber | ||
Maximum Working Pressure | 5 MPa | ||
Pressure Limit | 6 MPa | ||
Maximum Working Temperature | 250℃ | ||
Temperature Limit | 300℃ | ||
Outer Vessel Pressure Limit | 10 MPa | ||
Screen | 7 Inch Touch Screen | ||
Pressure Control Range | 0-5 MPa (0-50kg/cm2) | ||
Pressure Control Accuracy | 0.1MPa(1kg/cm2) | ||
Microwave Power | 1000 W,set from 0-1000W according to requirements | ||
Microwave Frequency | 2450MHz | ||
Chamber exhaust system | High-power?Blower, exhaust speed>5cbm/min | ||
Rotation Type | 360° continuous rotation | ||
Microwave Leakage | <5mW/ cm2 | ||
Power | AC 220V,10A,50/60Hz | ||
Size | 520mm×400mm×460mm | ||
Weight | 30kg | ||
