ZPW Series Triple-layers and Multifunctional Rotary Pill Press Machinery
US$ 30,000 - 40,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
PF
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port China( Mainland)
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ZP-5A 7A 9A Rotary Tablet Press, Professional Pill Making Machine for SaleUS$ 3,000 - 3,600MOQ: 1 Unit -
Top Selling ZP5 Small Tablet Power Press Machine, Tablet Compression MachineUS$ 2,600 - 3,000MOQ: 1 Unit
-
ZPW17D/ 19D Rotary Pill Press Machine, Pill Press Machine Machine for SaleUS$ 8,000 - 8,800MOQ: 1 Unit
-
Tablet Making Machine ZP-25 Pharmaceutical Rotary Punch Tablet Press MachineryUS$ 15,000 - 16,500MOQ: 1 Unit
-
Model ZP35/37/41D Rotary Tablet Compression Machine, With Good QualityUS$ 12,700 - 13,900MOQ: 1 Unit
Condition
New
Place of Origin
Shanghai, China
Brand Name
PF
Model Number
ZPW
Type
Rotary Tablet Press
Production Capacity
138000-204000pc/h
Max. Pressure(KN)
80KN
Max. Tablet Thickness(mm)
9mm
Max. Tablet Diameter(mm)
13-22mm
Voltage
380V
Power(W)
4kw
Weight
1800kg
Dimension(L*W*H)
640*480*1100mm
Certification
CE/ISO
After-sales Service Provided
Engineers available to service machinery overseas
ZPW Series Triple-layers and Multifunctional Rotary Tablet Press
1. technique paramete
Type | ZPW25 | ZPW31 | ZPW37 |
Dies | 25sets | 31sets | 37sets |
Max. Pressure | 80KN | 80KN | 80KN |
Max. Dia. of Tablet | 25mm | 18mm | 13mm |
Max. Depth of Fill | 18mm | 18mm | 18mm |
Max. Turret Speed | 46r/min | 46r/min | 46r/min |
single-layer Production Capacity double-layer | 138000pc/h 65000pc/h | 171000pc/h 80000pc/h | 204000pc/h 100000pc/h |
Motor | 4KW | 4KW | 4KW |
2. Application:
ZPW Multi-functional Rotary Tablet Press has a wide scope of application. It is applicable not only to the pharmaceutical and foodstuff industry but also the chemical, ceramic, electronic and battery industry for pressing the various kinds of granular materials into tablets.
The functions of the machine are complete. Besides producing the round shape tablets, it can also produce irregular, ring shaped or double engraved tablets. It can not only produce single layer tablets but also double layers or even triple-layers tablets to satisfy the different demands of the customers.
3. Features:
The machine is compatible to the GMP requirements, with the separation of the tablet -pressing compartment from the driving mechanisms, to prevent the contamination of the pharmaceutical. All the parts that will be in contact with the pharmaceutical materials are made of stainless steel or zinc plated in the surface, nontoxic and abrasion and corrosion resistant.
With the main machine and the operational control panel separated, the Model ZPW Multi-functional Rotary Tablet Press is convenient in operation and maintenance.
By adopting PLC programmable controller, the main functions, production data and malfunctions of the tablet pressing are monitored and controlled. By adopting inverter for the speed adjustment, the adjustment of speed is step-less and reliable with a wide range. Meanwhile, motor with frequency inverter has been selected, to ensure the constant power and speed adjustment with consistent torque, meeting the requirement on the torque with in the stipulated range for the rotary speed of the press.
4. Company introduce:
Our company is professional to do and export pharmaceutical machines, pharmaceutical packing material and others with a good reputation in the industry of China's pharmaceutical machinery
Our product include:
1). Kinds of drugs machinery: tablet press machine, capsule filling machine, blister packing machine, capsule filling machine, tablet coating machine, tablet/capsule counting production line, liquid filling machine, powder filling machine, liquid/powder/ cream packing machine and so on.
2). Tester equipment in laboratory
3). Packing material: empty capsule, PVC, Aluminum foil, glass bottle, plastic bottle, laminated aluminum foil and so on
5. Factory and exhibition photos:
Canton Fair show
Working room
6. Relation spare parts:
7. Other machines:
8. Pill samples:
9. Certificate
