ZPY120 Rotary Tablet Press
1. technique paramete
Model | ZPY120 |
Dies(sets) | 20 |
Die standard | IPT |
Max. pressure(Kn) | 80 |
Max. dia. Of tablet (mm) | 25 |
Max. depth of fill(mm) | 18 |
Max. thickness of tablet(mm) | 10 |
Turret speed(r/min) | 5-32 |
Max. production capacity (tablets/hour) | 38,400 |
Motor(kW) | 4 |
Overall size(mm) | 840*1015*1720 |
Net Weight(kg) | 1200 |
2. Application:
3. Features:
1. The machine is compatible with the GMP requirement.
2. The mechanism of the machine belongs to single-press type. It has a pre-pressing track and the pressure rollers have bearing so that it has a large the pressure. It is stable in operation.
3. The punch and dies meet the international IPT standard. It can produce large tablets.
4. The tablet-pressing room is easy to clean and maintain.
5. An overload protection unit is including in the system to avoid the damage of the apparatus.
6. It is used advanced machatronics unit and touch keyboard and screen display, the speed adjustment of the driver is controlled by the frequency conversion device, and it is used the concentrated lubricating system.
7.The transmission system is located inside the worm-gear box under the main body, and it is fully lubricated so that the polluted-ness and the abrasion are greatly reduced.
8. With the appliance of utility model patent, the ways to fix the lower track and lower pressing wheels are especial, so that be remounted conveniently and fast.
4. Company introduce:
Our company is professional to do and export pharmaceutical machines, pharmaceutical packing material and others with a good reputation in the industry of China's pharmaceutical machinery
Our product include:
1). Kinds of drugs machinery: tablet press machine, capsule filling machine, blister packing machine, capsule filling machine, tablet coating machine, tablet/capsule counting production line, liquid filling machine, powder filling machine, liquid/powder/ cream packing machine and so on.
2). Tester equipment in laboratory
3). Packing material: empty capsule, PVC, Aluminum foil, glass bottle, plastic bottle, laminated aluminum foil and so on
5. Factory and exhibition photos:
Canton Fair show
Working room
6. Relation spare parts:
7. Other machines:
8. Pill samples:
9. Certificate
