ZPW21 Series Rotary Tablet Press Machine
1. technique paramete
Type |
ZPW-21 |
ZPW-23 |
Dies (sets) |
21 |
23 |
Max.Pressure (kn) |
100 |
100 |
Max.dia.of tablet (mm) |
45 |
40 |
Max.thickness of fill(mm) |
12 |
12 |
Max.depth of fill (mm) |
25 |
25 |
duction capacity (pcs/h) |
21000 |
23000 |
Rotational diameter (mm) |
445 |
445 |
Rotational speed of revolving table (r/min) |
10-25 |
10-25 |
Diameter of middle mould (mm) |
45 |
45 |
Highness of up and down punch pole(mm) |
30 |
30 |
Length of up and down punch pole(mm) |
32 |
32 |
Length of down punch pole(mm) |
175 |
175 |
Length of down punch pole (mm) |
180 |
180 |
Overall dimensions (mm) |
1000×1250×1900 |
1000×1250×1900 |
Net weight (kg) |
3200 |
3200 |
Motor model |
YU132M4A |
YU132M4A |
Motor (kW) |
7.5 |
7.5 |
Voltage(V) |
380 |
380 |
2. Application:
3. Features:
A. Machine meet GMP and made in stainless steel. The inner tablet press surface already be special treated, which could keep surface luster and prevent from being polluted crossly.
B. Equipped with transparent window which could help to observe the status of pressing tablet. Transparent window could be fully opened, Machine easy to clean and Maintenance. All monitors and operating components work well together.
C. Machine speed could be adjusted.
D. Equipped with over-load protection apparatus. When pressure overloads, the machine will stop automatically.
E. Ransmitting system is sealed in the oil box under the working area, which work separately. No pollution and easy to send out heat and resist grinding.
F. .A power suction unit is attached to take the residual power during operation, so that blockage powder can be collected and be reused.
G. Mould is generally same with ZP19, ZP35 and ZP37 Tablet press machine.
4. Company introduce:
Our company is professional to do and export pharmaceutical machines, pharmaceutical packing material and others with a good reputation in the industry of China's pharmaceutical machinery
Our product include:
1). Kinds of drugs machinery: tablet press machine, capsule filling machine, blister packing machine, capsule filling machine, tablet coating machine, tablet/capsule counting production line, liquid filling machine, powder filling machine, liquid/powder/ cream packing machine and so on.
2). Tester equipment in laboratory
3). Packing material: empty capsule, PVC, Aluminum foil, glass bottle, plastic bottle, laminated aluminum foil and so on
5. Factory and exhibition photos:
Canton Fair show
Working room
6. Relation spare parts:
7. Other machines:
8. Pill samples:
9. Certificate
