ZP37A Large-scale Rotary Tablet Press Machine, Press Tablet Equipment Meet the GMP Standrad

Huizhou Pingfang Trading Co., Ltd.

ZP37A Large-scale Rotary Tablet Press Machine, Press Tablet Equipment Meet the GMP Standrad photo-1

US$ 30,000 - 33,000 MOQ: 1 Unit

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port China( Mainland)

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Shanghai, China

Brand Name PF

Model Number ZP37A

Type Rotary Tablet Press

Production Capacity 160,000pc/h

Max. Pressure(KN) 100KN

Max. Tablet Thickness(mm) 8mm

Max. Tablet Diameter(mm) 16mm

Voltage 380V

Power(W) 5.5kw

Weight 1800kg

Dimension(L*W*H) 1100 x 940 x 1500(mm)

Certification CE/ISO

After-sales Service Provided Engineers available to service machinery overseas

ZP-25 rotary tablet press machine

1. technique paramete

Dies(sets)	37
ure(Kn)	100
Max.Dia.of Tablet(mm)	Φ14 (16)
Max.Depth of fill(mm)	17
Max.Thickness of Tablet(mm)	8
Turret speed(r/min)	5~36
Production capacity(pcs/h)	160,000
Motor power(kW)	5.5
Overall dimensions(mm)	1100 x 940 x 1500(mm)
Net Weight(kg)	1800

2. Application:

The machine is a new generation product which is developed form the former ZP37 Tablet Press of our company, it is a double-press type, continuously automatic rotary tablet press for pressing tablets, it is widely applicable to industries such as pharmaceutical, chemical, foodstuff and electron for pressing the granular materials into all kinds of round tablets, irregular tablets ,two colors tablets and ring shaped tablets.

3. Features:

1. The machine is compatible with the GMP requirement, the outside part of the machine is fully enclosed, the material of the cover and the inside table face of the table-pressing room is stainless steel, the turret face has been disposed specially, nontoxic and smooth and abrasion proof.

2. The machine has a greatly large power and pressure, and it has two pieces of pre-pressing tracks It is stable in operation and is applicable to press hard-pressing powder.

3. An overload protection unit is including in the system to avoid the damage of the apparatus, when overload occurs, the machine stops automatically, and at the same time the alarm light turns on.

4. The speed adjustment of the driver is controlled by the frequency conversion device, it is easily to operated, safety and accurate.

5. According to the special need of consumers ,the function of communication network is to set equipment address and pass data in communication agreement criterion; it realizes higher-up managing equipment of work and output.

6. The centralized lubrication system of the machine can ensure the oil supply to every lubricating part by the intellectual lubricating pump, and it is very reliable.

7. To exert human nature ideas, the machine is easily to be cleaned and maintained.

8. The transmission system is located inside the worm gear box under the main body, and it is a fully independent part. It cannot be cross-polluted, and the transmission system is fully lubricated so that the noise and the abrasion are greatly reduced.

9. With the appliance of utility model patent, the ways to fix the lower track and lower pressure rollers are especial, so that be remounted and maintained conveniently and fast.

4. Company introduce:

Our company is professional to do and export pharmaceutical machines, pharmaceutical packing material and others with a good reputation in the industry of China's pharmaceutical machinery

Our product include:

1). Kinds of drugs machinery: tablet press machine, capsule filling machine, blister packing machine, capsule filling machine, tablet coating machine, tablet/capsule counting production line, liquid filling machine, powder filling machine, liquid/powder/ cream packing machine and so on.

Welcome to scan our website:

2). Tester equipment in laboratory

3). Packing material: empty capsule, PVC, Aluminum foil, glass bottle, plastic bottle, laminated aluminum foil and so on

5. Factory and exhibition photos:

Canton Fair show

Working room

6. Relation spare parts:

7. Other machines:

8. Pill samples:

9. Certificate
