Factory Price THP-II Flower Basket Tablet Pill Press Machine

Factory Price THP-II Flower Basket Tablet Pill Press Machine photo-1
Factory Price THP-II Flower Basket Tablet Pill Press Machine photo-2
Factory Price THP-II Flower Basket Tablet Pill Press Machine photo-3
Factory Price THP-II Flower Basket Tablet Pill Press Machine photo-4
Factory Price THP-II Flower Basket Tablet Pill Press Machine photo-5
Factory Price THP-II Flower Basket Tablet Pill Press Machine photo-6
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
PF Flower Basket Single Punch Big Tablet Press Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shanghai, China
Brand Name PF Flower Basket Single Punch Big Tablet Press Machine
Model Number THP-I Flower Basket Single Punch Big Tablet Press Machine
Type Single Punch
Production Capacity 2760 pcs/hour
Max. Pressure(KN) 100KN
Max. Tablet Thickness(mm) 35mm
Max. Tablet Diameter(mm) 40mm
Voltage 220V
Power(W) 2.6 KW
Weight 759KG
Dimension(L*W*H) 666*860*1824
Certification GMP ISO, ISO
After-sales Service Provided Engineers available to service machinery overseas


Factory Price THP-II Flower Basket Tablet Pill Press Machine


Applications



1. Single punch tablet press machine  is a continuous and automatic tablet press which is one of the most important equipments in pressing granular raw materials into tablets or medicines.

2. It is fit for the pressing of medicinal tablets, coffee pills, powder metallurgy, electronic elements, various tablets of pesticide and fertilizer etc. in pharmaceutical, chemical, food and electronic industries.

3. Single punch tablet press can be used in pressing special-shaped circular tablets, and tablets with both sides pressed with trademarks, letters and simple patterns. Big tablet making machine is widely used in small factory, laboratory and hospital.

4. Tablet press, is also can be called as tablet press machine, pill press machine, tablet compression machine and tablet making machine, is for pressing powder raw materials into tablets.



Features



1. Excellent performance, strong adaptability, convenient operation

2. Machine has big pressure. Could press big tablet, for small capacity

3. Material filling and depth adjusted

4. Machine could be operated by electricity and hands.

5. Machine could press different tablet size and tablet shape by changing mould.





Model

THP

THP-I

THP-II

Maximum Pressure(KN)

40

100

100

Maximum Dia. of Tablet(mm)

30

40

50

Maximum Filling Depth(mm)

25

45

45

Maximum Thickness of Tablet(mm)

22

35

35

Annular Tablet aperture(mm)

5-10

6-14

6-14

Filling Depth of Circular Tablet(mm)

25

25

45

Weight(KG)

520

750

770

Production Capacity(pieces/hour)

3000

2760

2760

Motor power(KW)

1.1

2.6

3.7

Overall Size(mm)

685 x 565 x 1610

666 x 860 x 1824

666 x 860 x 1824


Pictures

                                          Machine Show
