PG Series Automatic High-speed Tablet Press Machine (620)

PG Series Automatic High-speed Tablet Press Machine (620) thumbnail-1
PG Series Automatic High-speed Tablet Press Machine (620) photo-1
US$ 83,000 - 91,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
PF
Contact Supplier Request Quote Chat Now
Huizhou Pingfang Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port China( Mainland)
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name PF
Model Number PG
Type Other, high speed tablet press
Production Capacity 124800-585000 pc/h
Max. Pressure(KN) 100KN
Max. Tablet Thickness(mm) 8-10mm
Max. Tablet Diameter(mm) 25mm
Voltage 380V
Power(W) 11kw
Weight 3800kg
Dimension(L*W*H) 1510*1380*2000mm
Certification CE/ISO
After-sales Service Provided Engineers available to service machinery overseas

                 PG Series Automatic High-speed Tablet Press Machine (620)


1.   technique paramete



      model
data
PG-45
ZPTS-45
PG-55
ZPTS-55
PG-65
ZPTS-65
No. of stations
45
55
65
Tooling type
D
B
BB
Output range(tablets/h)
84600-405000
105600-495000
124800-585000
Rotation speed range(rpm)
16-75rpm
Main pressure
100KN
Pre-pressure
16KN
Max tablet diameter
25mm
16mm
13mm
Max length of irregular tablet
25mm
19mm
16mm
Diameter of die
38.1mm
30.18mm
24mm
Max. filling depth
20mm
20mm
16mm
Diameter of punch
25.35mm
19mm
Length of punch
133.6mm
Pitch circle diameter
620mm
Main motor power
11kw
Weight
3800kg
Dimension
1510*1380*2000mm









2. Application:

Meets GMP requirement can press two layers tablets with different colors, annular tablets, round tablets, engraved tablets and irregular tablets.Available for pharmaceutical factory, food and chemical industries.



3. Features:

A.   Tablets formed Twice by main pressing and pre-pressing .
B.   Central auto lubrication system
C.   Double-sided output, high efficiency.
D.   Force-feeding device controls the flow of powder and ensures the accuracy of feeding. Feeder is easy to be disassembled, and the platform is easy to be regulated. No dead area in press chamber and easy to be observed and cleaned.
E.   Imported hydraulic pump unit sustains main pressure and pre-pressure, process of pressing goes smoothly with low noise ;
F.   Equipped with protective unit of overloading, auto stopped while pressure overland.
G.   An easy disassembled structure has high maintainability.




4. Company introduce:

Our company is professional to do and export pharmaceutical machines, pharmaceutical packing material and others with a good reputation in the industry of China's pharmaceutical machinery



Our product include:

1). Kinds of drugs machinery: tablet press machine, capsule filling machine, blister packing machine, capsule filling machine, tablet coating machine, tablet/capsule counting production line, liquid filling machine, powder filling machine, liquid/powder/ cream packing machine and so on.

Welcome to scan our website:

2). Tester equipment in laboratory

3). Packing material: empty capsule, PVC, Aluminum foil, glass bottle, plastic bottle, laminated aluminum foil and so on



5. Factory and exhibition photos:

PG Series Automatic High-speed Tablet Press Machine (620)

Canton Fair show
PG Series Automatic High-speed Tablet Press Machine (620)

PG Series Automatic High-speed Tablet Press Machine (620)

Working room



6. Relation spare parts:
PG Series Automatic High-speed Tablet Press Machine (620)



7. Other machines:

PG Series Automatic High-speed Tablet Press Machine (620)PG Series Automatic High-speed Tablet Press Machine (620)





8. Pill samples:

PG Series Automatic High-speed Tablet Press Machine (620)PG Series Automatic High-speed Tablet Press Machine (620)





9. Certificate

PG Series Automatic High-speed Tablet Press Machine (620)PG Series Automatic High-speed Tablet Press Machine (620)PG Series Automatic High-speed Tablet Press Machine (620)
