Normal Saline Non-PVC Film Multi-chamber I.V Infusion Soft Bag Production Line

Huizhou Pingfang Trading Co., Ltd.

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Apparel, Beverage, Chemical, Commodity, Food, Medical, Textiles

Packaging Type:

Case

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port China(Mainland)

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Apparel, Beverage, Chemical, Commodity, Food, Medical, Textiles

Packaging Type Case

Packaging Material Wood

Automatic Grade Automatic

Driven Type Electric

Voltage 380V

Power 32KW

Place of Origin Hunan, China

Brand Name PF

Model Number SRD Series

Dimension(L*W*H) 14685*3500*2100

Weight 15000kg

Certification GMP

After-sales Service Provided Engineers available to service machinery overseas

Normal Saline Non-PVC Film Multi-chamber I.V Infusion Soft Bag Production Line

Specifications

Normal Saline Non-PVC Film Multi-chamber I.V Infusion Soft Bag Production Line

1.Multi-chamber
2.It avoids the chemical reaction and decrease of drug effect caused by the mixture of different medicines.

Function and Feature

Applying advanced technology, reasonable construction, stable, reliable performance.
Fully automatic, intellectulized control, controlling components and actuator all choose famous international brand.
Making-bag and filling-sealing performs simultaneously, decreasing the second possible pollution in the intermediate course, which conforms to GMP requirement.
It has color-belt printing system. Trade mark, product instruction, lot number, production date can be printed simutaneously.
Adopting advanced filling method, accurate metering, no particles caused by mechanical friction, no bag no filling. The filling amount of each filling head can be inputted or changed by way of man-machine interface, adjusting metering is extremely convenient.
The filling system can be realized CIP and SIP.
Air from bag can be exhausted before the bag is sealed.
Adopting insert adapter method to seal, tight sealing and no pollution.
Wide use, it can produce different kinds of soft bag I.V product with multi-chamber bag, triple-chamber bag, single-chamber bag with double tube.
Adopting patent technology of no waste edge mould. Bag with the same size can decrease 3.7%mould amount and productive cost effectively.
Choosing material carefully, beautiful appearance.

Technical parameters

Production capacity	3000 bags/hr
Bag film	Non-PVC double layer flat film
Film thickness:	190±20um
The inner diameter of film roll	150mm
Outer diameter (max.)	600mm
Pipe adapter	inner diameter6.1mm,outer diameter8.1mm
Size	single chamber:100ml, 250ml, 500ml multi-chamber:20ml/100ml. 20ml/250ml, 20ml/500ml
Lettering method	concolorous, heat foil printing
Filling error	large capacity≤±2% small capacity ±1%
Electric capacity	32kw,380v 50Hz
Compressed air	pressure 6bar (dry, free of oil) consumption 4000L/min
Clean compressed air pressure (hundred degree)	4bar
Consumption	1000L/min
Cooling air	500L/hr, 5~10ºC
Noise (max.)	75dB
Material	stainless steel (Contacting part with drug solution is 316L)
Weight	15000kg
Overall dimension	14685×3500×2100 (L×W×H)
