SR Series of Non-PVC soft bag I.V.-solution Production Line with best quality for sale
1. Application:
SR Series Non-PVC soft bag IV-solution production line is the highest efficiency product line, which is compiling all the most advanced technique. It is the upgrading and updating products for existing IV-solution production line, can finish such procedure as printing word, bag-making, bag-filling and sealing.
2. Features:
--Applying the advanced technology,it has reasonable structure and stable, reliable feature..
--Chinese touch screen operation, aptitude control. Time ,temperature ,pressure and filling mete .etc .parameter can be settng and monitoring by computer.
--The machine memory is very strong. Aims at different film material, user can storage the practice welding parameter , when changes film it can be used directly.
--It can set automatic start; make the machine warm-up, in order to guarantee enough running time.
--The filling system adopts mass flowmeter to metering, high precision and wide range for filling quantity, and can realize CIP/SIP.
--It has high arranges . The servo system ,PLC, pneumatic elements and so on, are complete select and use international brand, assure to run in steady and reliable.
--Its structure is unique, and the produce efficiency is high, it can produce 6000 single chamber or multi – chamber soft bags every hour.
--For patent design, The production line becomes bag making , filling and sealing integrated machine its length is compressed 1/3, the area of workshop and air-conditioner purify are decreased 1/3, so it can decrease the investment cost and use cost in furthest.
Suitable packing material |
CIP/SIP Sterilizing and Filling System |
Bag Form |
Form of pipe orifice |
Precision of Filling |
|
Double Layer Sheet Film |
Style of time/Pressure
Style of Mass Flow |
Single(double) Single chamber bag
Single (double)powder(Liquor)/Liquor Multi- charmbers bags
Special bag style |
Round soft port
Round hard port
Boat port |
50ml±1.5%
100ml±1.5%
250ml±1.0%
500ml±0.7% |
3. Technical Parameters:
Order code |
SRD2A/2500 |
SRS2A/2500 |
SRD4A/4600 |
SRS4A/4600 |
SRD6A/7000 |
SRS6A/7000 |
|
Max. productivity |
2500Bags/h |
4600bags/h |
7000bags/h |
|||
Capacity |
100ml,250ml,500ml |
50ml,100ml,250ml,500ml |
||||
Q’ty/ cylcle |
2 |
2 |
4 |
4 |
6 |
6 |
|
Interface Methods |
Boat interface |
Tube interface |
Boat interface |
Tube interface |
Boat interface |
Tube interface |
Power source |
3 Phases 380V 50Hz |
|||||
Power |
20kw |
6kw |
30kw |
7kw |
32kw |
8kw |
Compressed air pressure |
Dry and oil free compressda air, the cleaness in 5um, the pressure is over 0.6Mpa, automatically stop and warning signals when it is too low. |
|||||
Clean air pressure |
The neat air is over 0.4Mpa, and it’s cleanliness is 0.22um |
|||||
Cooling water pressure |
>0.5kg/cm2 |
None |
>0.5 kg/cm2 |
None |
>0.5 kg/cm2 |
None |
Over size |
6.4mx2.5m x2.1m |
8.1mx4.7m x2.1m |
8.5mx2.7m x2.1m |
12mx4.7mx2.1m |
10.6mx2.4mx2.1m |
13mx4.7mx2.1m |
Weight |
7.6ton |
10.8ton |
12.0ton |
|||
5. Machine shows:
6.Our customers:
