DZ-120 CE Standard Injection Cartoning Machine, Vertical Cartoning Machine
The equipment is mainly used for automatic packaging of injection drugs in trays or injection in bubble cap board trays and similar specifications’ items, and if it can connect the front printing equipment or equipment of making trays connecting printers, this will improve productivity.
1 The speed is regulated by variable frequency and automatic control system.
2 The machine adopts man-machine interface operating system, automatically display box speed, quantity and other
3 performance parameters, and also display the fault causes and methods of operation and maintenance.
4 It can be implemented that adjust and use of more specifications at the specific confine on the same machine.
5 Manual and automatic conversion
6 It can print three bath numbers on the box and also have the functions of print serial numbers.
7 Incorporates automatic inspection system and has the functions of automatic suspension and removal of non-conforming products.
Item |
Parameters |
|
Encasing speed (fill by manual way) |
70-100 boxes /min |
|
Dimension range(L×W×H) |
(100-160)mm×(70-130)mm×(20-50)mm |
|
Unfolded leaflet specification |
(80-160)mm×(90-190)mm |
|
Compressed air |
Working pressure |
≥0.6mpa |
Power supply |
380V 50HZ |
|
Main motor power |
1.2kw |
|
Machine dimension(L×W×H) |
2400mm×1140mm×1800mm |
|
Machine weight |
1300kg |
|
