Help CenterDZ-120P Fully Automatic Bottle Cartoning Machine for Cosmetics
Related Products
-
DZH-120P High Efficiency Horizontal Type Automatic Carton Packing Machine for BottlesNegotiableMOQ: 1 Unit -
BT-2000L Three-dimensional Automatic Packaging Machine/Cellophane Overwrapping MachineNegotiableMOQ: 1 Unit
-
DZ-120 Automatic Cartoning Machine/Injection Type Cartoning MachineNegotiableMOQ: 1 Unit
-
DZ-120B Blister Card Cartoning Machine/vertical Cartoning MachineNegotiableMOQ: 1 Unit
-
DZ-120D Facial Mask Automatic Cartoning Machine, Cosmetic Packaging MachineNegotiableMOQ: 1 Unit
This equipment is new model developing base on integrated domestic and foreign vanguard technology .It is high technology product incorporates pneumatic-photo-electro-mechanic which improve by a large on performance of equipment and working efficiency, realize encasing fast, keep running steady and reliable when fast running.
This machine is suitable for automatic feeding bottle(round,square bottle)into carton (either for blister or bottle). On line bottle unscramble and feeding,leaflet fold(1-4folds) and feeding,leaflet detecting,canton opening and forming,products and leaflet pushing into carton,printing batch number,sealing carton with tuck-in or hot melt glue device. Automatically reject lacking of leaflet or product and finished product out.
1 International famous brand of electrical component such as PLC touch screen, frequency inverters, etc.
2 Adopt human-machine operation system.
3 Automatically stop when machine is overload.
4 Automatically reject lacking of package product and leaflet.
5 Automatically display trouble, Alarm and count finished products.
6 Stable performance, operation is easy.
Item |
Parameters |
|
Encasing speed |
30-120 boxes /min |
|
Box |
Quality requirement |
250-350g/m2[Base on carton size] |
Dimension range(L×W×H) |
(65-120)mm×(30-70)mm×(15-55)mm |
|
Leafle |
Unfolded leaflet specification |
(80-230)mm×(90-170)mm |
Fold range |
[1-4]Fold |
|
Compressed air |
Working pressure |
≥0.6mpa |
Air consumption |
120-160L/min |
|
Power supply |
380v 50HZ |
|
Main motor power |
0.75kw |
|
Machine dimension(L×W×H) |
2600mm×1140mm×1800mm |
|
Machine weight |
1200kg |
|
