XC-180 Wire Stripping & Twisting Machine

XC-180 Wire Stripping & Twisting Machine photo-1
US$ 210 - 240 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
BOJIN
Model Number:
XC-180
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name BOJIN
Model Number XC-180
Usage Stripping

XC-180 Wire Stripping & Twisting Machine





1.Usage:
worked by the micro-motor. The machine is small and easy to move, low voice, fast speed. Apply for the single-multi plastic and copper wire's striping and twisting. Can strip and twist at the same time.



2. Performance and parameters:
Model: XC-180
Input voltage: AC220V/50Hz
power: 40W

 Weight: 6Kg
Processing Range: 1-4mm
Processing range: 0.1-1.5mm²

Striping length: 2-20mm
Specifiion: 210L×125W×155Hmm



3. Procedures of operation:
a. first please set the length of the wire.

b. according to your line size, select the matched die approach, then you need adjust the length of the wire which needed   twisting and striping.
c. start the machine.
d. setting the parameter machinery speed.
e. quickly put the wire into the die approach,  and quickly pull out at the same time, and then it is finished .



XC-180 Wire Stripping & Twisting Machine

We Provide

  • Best products and factory price.
  • On-time delivery and the shortest delivery time.
  • 1-year warranty. If our products cannot function properly within 12 months, we'll offer spare parts for free; and you need to pay for the delivery.
  • OEM and customized service.
  • User manuals will go with relative machines.

Service

  • QC: All products will be checked before delivery.
  • Compensation: If any unqualified product is found, we'll pay the compensation or send new qualified products to customers.
  • Maintenance & Repair: In case of any maintenance or repair need, we'll help to find out the problem and offer relative guidance.
  • Operation Guidance: If you have any problem with operation, please feel free to contact us.
