Electric Heating Element Resistance Wire Cutting Machine

Name: Electric Heating Element Resistance Wire Cutting Machine
Brand: BOJIN
SKU: 141102296
Availability: InStock

US$ 1,700 - 1,800 MOQ: 1 Unit

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

BOJIN

Model Number:

XC-801

Kunshan Bojin Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name BOJIN

Model Number XC-801

After-sales Service Provided No overseas service provided

electric heating element resistance wire cutting machine Features
Fit for cutting sheet copper, hot-shrunk tube, PVC tube, electrode, plastic sheet, flat ribbon cable etc. Step motor control, high accuracy. Cutting length fine tuning (depending on wire material) Single-step / continuous operation. Can carry inching operation in wire feeding and cutter alignment.
Specifications
Model:	XC-801
Shape Size:	450mmX 370mmX 340mm
Weight:	45Kg
Display Way:	Digital Display
Power Supply:	AC220V/50Hz
Power Rating :	150W
Cutting Length:	0.1mm~10m
Cutting Tolerance:	0.002 X L mm(L=Cutting Length)
Cutting Width:	0.1mm - 100mm
Rollers Press Adjustment:	Setup
Speed Adjustment:	0-9
Drive Way:	Two Rollers Drive At The Same Time

We Provide

Best products and factory price.
On-time delivery and the shortest delivery time.
1-year warranty. If our products cannot function properly within 12 months, we'll offer spare parts for free; and you need to pay for the delivery.
OEM and customized service.
User manuals will go with relative machines.

Service

QC: All products will be checked before delivery.
Compensation: If any unqualified product is found, we'll pay the compensation or send new qualified products to customers.
Maintenance & Repair: In case of any maintenance or repair need, we'll help to find out the problem and offer relative guidance.
Operation Guidance: If you have any problem with operation, please feel free to contact us.

...
