GM47L-1 DC Type Air compressor
sage: drilling machine, pneumatic tools, vehicle braking, doors and windows open and close by, textile machinery, tire inflation, mining compressors, marine compressors, sand blasting, spray painting
Performance Low Noise
highly reliable and durable valve
The overall strength aluminum alloy body, light and heat
Motor delivers reliable power, low-voltage start running performance
Powerful fan cooled motor and body simultaneously
Special shock absorber design
dual exhaust nozzles. Are used to direct the exhaust vent and pressure regulator
with sliding button pressure switch, convenient and safe
| Model | GM0302 | GM0208-2 | GM0208-3 | GM47L-1 | GM47L-2 | GM47L-3 | GMW0301 | GMW0305 | GMW2025 |
| Pressure | 0.7Mpa | 0.7Mpa | 0.7Mpa | 0.7Mpa | 0.7Mpa | 0.7Mpa | 0.7Mpa | 0.7Mpa | 0.7Mpa |
| Exhaust volune | 0.20m3/min | 0.10m3/min | 0.10m3/min | 0.12m3/min | 0.12m3/min | 0.12m3/min | 0.14m3/min | 0.12m3/min | 0.198m3/min |
| Motor | 2.2KW/3HP | 0.75KW/1HP | 0.75KW/1HP | 1.5KW/2HP | 1.5KW/2HP | 1.5KW/2HP | 1.875KW/2.5HP | 1.5KW/2.5HP | 1.5KW/2HP |
| Cylinder | 42mm ×2 | 42mm ×1 | 42mm ×1 | 47mm ×1 | 47mm ×1 | 47mm ×1 | 41mm *1 | 47mm *1 | 61mm *1 |
| Storage tank | 30L | 6L | 6L | 24L | 24L | 24L | 35L | 50L | 25L |
| Size | 63×42×61cm | 47×21×47cm | 47×21×47cm | 60×31×58cm | 60×31×58cm | 60×31×58cm | 70×30×58cm | 80×32×67cm | 60×30×59cm |
| Weight | 36Kg | 21Kg | 21Kg | 27Kg | 27Kg | 27Kg | 32Kg | 37Kg | 24Kg |
