Yuxiang machinery Fine craft double wheel Grinding gold machine
- 100 Set / Sets per Month
- Qingdao / Shanghai /Tianjin
- T/T L/C D/P D/A Credit Card PayPal
Product Details
| Condition: | New | Type: | Ball Mill | Motor Type: | AC Motor |
| Power(W): | 7.5kw | Capacity(t/h): | 0.8-1t | Place of Origin: | Henan, China |
| Brand Name: | Yuxiang | Model Number: | 1200A | Dimension(L*W*H): | 2.3*2.3*2 |
| Weight: | 5.5t | Certification: | CE ISO | Warranty: | 12 Months |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
high efficient Minning pan mill seperation double wheel Grinding gold machine Wet Pan Mill with best after service
Standard technical Yuxiang machinery Grinding Wet Pan Mill
here goes the product working viedo: https://youtu.be/Z_PzLuXl1_k
 | Grinding Wet Pan Mill /Gold grinding machine is the best equipment to replace ball mill. because it have small investment, high output, low production cost, good efficiency and easy installation. And the machine is the ideal beneficiation equipment for small and medium-sized enterprise. Gold grinding machine is mainly used to process the gold, silver, lead, zinc, iron, molybdenum, copper, antimony. |
| The wet pan mill is named by the diameter of roller. Φ1300,Φ 1350,Φ 1400,Φ 1500,Φ 1600 is suitable for selection of iron ore, molybdenum ore ,lead ore ,zinc ore, antimony ore and so on. Φ 850, Φ 900, Φ 1000,Φ 1100,Φ 1200 is suitable for selection of gold ore. Above all, 1200a type is the most popular and widely use. | |
Working principle of gold processing machine
| The machine repeatedly squeeze and mill gold ore through the weight of the wheels until the gold ore has been crushed completely. And then add 1 kg mercury into the water . Meantime, every 5-10 minutes, add gold ore to the machine. After 24 hours, recycle mercury. Then pack mercury with big density of cloth. Twist the cloth and let the mercury come out. The gold will be left in the cloth. |
| Model | Dia of grinding wheel(mm) | Thickness of grinding wheel(mm) | Dia of grinding pan (mm) | Thickness of grinding pan (mm) | Working surface of wet pan mill (mm) | Speed (r/min) | Power (kw) | Weight (t) |
| YX-1600A | 1600±10 | 400±10 | 2100±10 | 200±10 | 500±10 | 20-22 | Y6-37 | 14.5 |
| YX-1500A | 1500±10 | 400±10 | 2050±10 | 200±10 | 460±10 | 20-22 | Y6-30 | 13.5 |
| YX-1400A | 1400±10 | 250±10 | 2000±10 | 170±10 | 350±10 | 16-18 | Y6-15 | 8.5 |
| YX-1300A | 1300±10 | 250±10 | 2000±10 | 150±10 | 250±10 | 16-18 | Y6-15 | 7.5 |
| YX-1200A | 1200±10 | 200±10 | 1800±10 | 90±10 | 250±10 | 17-19 | Y6-7.5 | 5.5 |
| YX-1200B | 1200±10 | 200±10 | 1800±10 | 90±10 | 250±10 | 23-25 | Y6-7.5 | 5.5 |
| YX-1100A | 1100±10 | 200±10 | 1800±10 | 90±10 | 250±10 | 17-19 | Y6-7.5 | 5 |
| YX-1000 | 1000±10 | 200±10 | 1700±10 | 90±10 | 250±10 | 13-15 | Y6-7.5 | 4.5 |
| YX-900 | 900±10 | 180±10 | 1700±10 | 80±10 | 250±10 | 13-15 | Y6-5.5 | 4.5 |
Grinding base For model 1200A, the diameter of grinding base is 1800mm and the the thickness is 90mm. The material could be high Mn and White irone. | |
| Grinding roller The smooth surface design will be good for the grinding efficiency.The material could be high Mn and White iron. For 1200A model grinding roller, the diameter is 1200mm, thickness is 200mm. weight is 1.5t/pcs. |
Water pan The edge of the water pan is specially processed with the edge protecting. | |
The working site of gold processing machine
The customer visit our company
1100A wet pan mill for Eygpt
this type is usually used by Eygpt customer,mainly used to process the gold ,sliver,lead,zinc ,iron,copper, Capacity:0.8-1t/h Weight:4.5t More details>>>
Get Quotation | |
| hammer crushers also called hammer mill,is suitable for crushing various hard and brittle materials. Weight:3.5t,0.8t Capacity:5-75t/h More details>>>
Get Quotation |
Jaw Crusher is suitable for crushing big size lumps in large quantity, is configured for primary crushing of even the hardest rock. Weight:10.3t Capacity:50-60 t/h Max Feeding Size:850mm More details>>>
Get Quotation | |
| Ball mill Yu Xiang's major product, professional technology support and all-around service can be offered to you Weight:37000KG Capacity:0.65-90T/H More details>>>
Get Quotation |
We know well the problems you will meet during the equipment working,know the mentaince ways and the spear parts needed.Of course,We would like to recommend suitable equipment according to your requirement
Gongyi city Yuxiang Heavy Machinery Co,Ltd has established more than 20 years, our mainly product Mining series equipment, Charcoal briquette machine series, Carbonization furnace equipment, Dryer series equipment, Grinding machine series,oil press machine/oil filteration machine etc.
