[ROTEX MASTER] Carbon steel wood saw dust pellet rotary dryer In China
( /watch?v=vrftblW-9_8 )
>>. What you need to know:
1. rotary drum dryer is mainly to dry biomass or Fertilizer or animal feed powder materials , it has rotary drum and can dry high humidity materials, such as sawdust, straw, stalk, animal feed materials from maize, soybean,cereal fertilizer materials from poultry manure , home or factory waste etc .
2. rotary drum dryer drum RPM can be controlled according to raw materials humidity. If humidity is large, then can control feeding speed lower and drum RPM lower to make longer drying time.
3. rotary drum dryer has temperature adjusting equipment between stove and dryer, which can adjust hot air temperature when feeding to dryer drum according to raw materials humidity and outlet stove hot temperature.
4. rotary drum dryer has two ways to discharge materials, one is to outlet from rotary drum bottom, it is mainly fit for large weight ratio materials , the other is to outlet materials from cyclone bottom , which mainly fits for light materials . so please tell us what kind of raw materials and dimension, raw humidity, then we will help you choose best dryer model.
>>. Consist of Sawdust Dryer
>>. Advantage of Sawdust Dryer
1. Reasonable design of raising board and angle ensure the material well-distributed and dry with less time. It owns reliable operation and high energy utilization ratio, simple maintenance.
2. Adopt an adjustable center tug structure, the good cooperation of the tug and the rolling ring reduce the attrition and energy consumption.
3. Special structure of the dam-wheel decrease the horizontal thrust, when the machine working in inclination station, it has strong ability of anti-overloading, steady operation and high reliability.
4. High temperature resistance. It can use the high temperature to dry the material quickly,
5. Large capacity, few fuel consumption, low drying cost
>>.Rotary dryer length 24 meters was divided into two parts
>>.Rotary dryer with Fan Blower 37kw
>>.Rotary dryer YGHG2.2*24m with Double 1000*2 Cyclone
>>.Rotary dryer Air Lock with #500
>>.Rotary dryer Can use heat stove: clients can choose to make the heat stove on site in
their factory, we can free offer the drawning.
>>.Rotary dryer can also choose biomass pellet burner as its heat sources, we can offer
walls stoping the fire.
>>. Technical Parameter of Sawdust Dryer
Model | Inner diameter (mm) | Power(kw) | Evaporation (t/h) | Feed water | Discharge water | Inlet temperature | Outlet temperature | Weight(t) |
YGHG0.8*12m | 800 | 5.5 | 0.2-0.3 |
20-50% |
10-20% |
400-600°C |
60-90°C | 3 |
YGHG1.0*12m | 1000 | 7.5 | 0.4-0.5 | 3.5 | ||||
YGHG1.2*12m | 1200 | 7.5 | 0.4-0.5 | 4.2 | ||||
YGHG1.4*12m | 1400 | 7.5 | 0.6-0.8 | 4.8 | ||||
YGHG1.5*12m | 1500 | 7.5 | 0.8 | 6.2 | ||||
YGHG1.6*12m | 1600 | 7.5 | 0.8-1 | 6.8 | ||||
YGHG1.6*24m | 1600 | 15 | 1-0.2 | 12.8 | ||||
YGHG1.8*12m | 1800 | 11 | 0.8 | 7.2 | ||||
YGHG1.8*24m | 1800 | 15 | 1 | 14.8 | ||||
YGHG2.0*12m | 2000 | 11 | 1.2 | 14.2 | ||||
YGHG2.0*24m | 2000 | 15 | 1.5 | 25.9 | ||||
YGHG2.2*12m | 2200 | 18.5 | 1.2 | 14.5 | ||||
YGHG2.2*24m | 2200 | 22 | 1.8 | 28 | ||||
YGHG2.5*12m | 2500 | 18.5 | 1.5 | 15.8 | ||||
YGHG2.5*24m | 2500 | 22 | 1.8 | 23.8 | ||||
YGHG2.8*12m | 2800 | 30 | 1.8 | 16.7 | ||||
YGHG2.8*24m | 2800 | 37 | 2.4 | 31.5 |
>>. Clients' Cases of Sawdust Dryer YHGH 2.2*24M
>>. What we need to know:
Please let us know the following basic information for making project
1. What are the materials do yo want to dry?
2. What capacity do you want for an hour?
3. What is the water content before drying?
4. What is the water content after drying?
Customers from Abroad for testing pellet machine
Pellet Dryer Production Line Certificates
3D Designed for customer according to his warehouse size and machines list
