Specifications
1.model:CFKJ8502.dimension:3300*1400*3100mm
3.power:220kw
4.weight:14500kg
5.capacity:2500-3500kg/h
Large Output wood pellet mill, wood pellet machine
wood pellet mill, wood pellet machine introduction
1) Biomass pellet capacity:1-1.5 T/H 90KW
2) Diameter of pellets:4-12mm
3)CE,SGS pellet making machine
4) Pellet making machine has lubricating System, which can save much time.
And it is suitable for long time working.
5) Vertical ring die pellet machine
materials for the wood pellet mill
rice husk, sunflower seed husk, peanut shell and other fruit shell;
Crushed branch ,trunk, bark and other wood waste;
corp straws, rubber, cement, ash and other chemical materials
The finished pellet is featured with high intensity, high combustion values, low water /ash content
Function of Wood Pellet Mill, wood pellet machine
granulating the crude fiber such as straw, wood, grass, sawdust, rice husk, cotton stalk, cotton seed skins, weeds and crop stalks, also making other plant waste into bio-fertilizer.
Application of wood sawdust pellet mill:
The equipment is applied to the materials with low adhesiveness and low shaping, such as the rice husk, sunflower seed husk, peanut shell and other fruit shell, branch trunk, bark and other wood waste ,a variety of straws, rubber, cement, ash and other chemical materials .this type of pellet mill is widely used in the biomass-energy fuels plant, wood processing plant, fertilizer plant, chemical plant etc. it is the ideal pressing shaping equipments with low investment and high profit.
| Model | Outpyut(t/h) | Power(kw) | Pellet Size(mm) | Weight(t) | Dimensions |
| JK450 | 0.4-0.7 | 55 | Φ4-2 | 2.1 | 1250*100*1600 |
| JK560 | 1-1.5 | 90 | Φ4-12 | 6.1 | 2600*1300*2300 |
| JK580 | 1.5-2.5 | 160 | Φ4-12 | 7 | 2900*1300*2400 |
| JK850 | 2.5-3.5 | 220 | Φ4-12 | 14. | 3300*1400*3100 |
| JK880 | 3-5 | 315 | Φ4-12 | 18 | 3800*1680*3400 |
| JK1050 | 5-8 | 360-450 | Φ4-30 | ||
| JK1250 | 8-12 | 550-660 | Φ4-30 |
Pictures
Working principle of Factory-outlet straw fuel pellet mill:
1. Pellet Mill: With the pellet mill interaction pressure between flat-die and pinch-roller and the friction of die hole taper ,the raw materials can form through the self-bounded fiber of the straw materials without any added bonding agent.
2. Pellet Mill Wide Material adaptable:Pellet mill adapt to a variety of biomass materials in shape, raw straw material with the length from powder to 50mm and the moisture content10-30% all can be processed.
3. Pellet Mill Electric heating function: Pellet mill with full automatic electric heating device can meet the needs of forming temperature and auto-add raw materials to pellet machine and adjust the density of finished products.
4. Wheel pressure automatic adjustment function: The use of Bi-direction Thrust bearing principle to adjust the pressure angle automatically, so that pellet mill molding can avoid raw material squeezing and does not work ,to ensure the stability of forming pellet.
5. Easy Operation: With high degree of automation, only two people are enough to operate the pellet machine, it is both ok to load materials manually and automatic loading by conveyor.
6. Process of the entire link:Raw materials acquisition → crushing → drying →convey to pellet mill → forming the pellet you need→put the finished product in storage
