Adjustable belt conveyor
- 1000 Set / Sets per Month
- Qingdao shanghai Tianjing Dalian Lianyungang all inland port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
Condition | New | Type | Slat Conveyor | |
Material | Rubber | Material Feature | Other, wear-resisting | |
Structure | Belt Conveyor | Load Capacity | according to different types | |
Place of Origin | Henan, China | Brand Name | Hongyun | |
Model Number | Adjustable belt conveyor | Power(W) | according to different types | |
Dimension(L*W*H) | according to different types | Certification | CE,ISO | |
After-sales Service Provided | Engineers available to service machinery overseas |
Adjustable belt conveyor has standard export package,also can do special package as customers' need.
Product Description
Adjustable belt conveyor
Belt conveyor is a kind of continuous transmission equipment which makes the friction force as driving source. And it can transmit granular, powder and block finished materials.
Advantages:
1 The belt conveyor runs smoothly, thus it can do a large quantity of transmission work;
2 The length can be adjusted according to users’ needs. It also can be used as a series by connecting each other to make up for the disadvantages of production environment. At the same time, it can reduce the use of labor force.
3 Wide application range. It can easily transfer materials in many kinds of industries.
4 More automotive and easily controlled centralized. Besides, it can adjust the transfer speed and the quantity of flow.
5 Because of its simple structure and light rack, it is easy for disassembling and assembling to make the dairy maintenance convenient.
6 There is no leakage of materials when running because of its compact structure and good sealing.
7 Low investment cost. It has strong universality and can be used in many industries.
8 It can be extended and shortened according to the working needs and can adjust the driving equipment to meet the production needs.
Specifications:
Conveyor width(mm) | Conveyor length(m)/power(kw) | Conveyor speed(m/s) | Conveying capacity(t/h) | ||
400 | ≤12/1.5 | 12-20/2.2-4 | 20-25/4-7.5 | 1.3-1.6 | 40-80 |
500 | ≤12/3 | 12-20/4-5.5 | 20-30/5.5-7.5 | 1.3-1.6 | 60-150 |
650 | ≤12/4 | 12-20/5.5 | 20-30/7.5-11 | 1.3-1.6 | 130-320 |
800 | ≤6/4 | 6-15/5.5 | 15-30/7.5-15 | 1.3-1.6 | 280-540 |
1000 | ≤10/5.5 | 10-20/7.5-11 | 20-40/11-22 | 1.3-2.0 | 430-850 |
1200 | ≤10/7.5 | 10-20/11 | 20-40/15-30 | 1.3-2.0 | 655-1280 |
Company Profile

Gongyi Xiaoyi Hongyun machinery factory has 20 years of production experience and performance in the mineral processing equipment and baking-free brick equipment industry, which changes from state-owned enterprise to private enterprise. We have been being committed to product the coal gangue crusher, shale crusher, fine crusher and slag crusher, and improve constantly their performance and efficiency. Recently, combined with foreign advanced technology, we developed three-warehouse compound crusher and three-warehouse fine crusher, which both make high efficiency and energy saving as the theme. Gongyi Xiaoyi Hongyun machinery factory has a modern enterprise management system, first-class equipment, perfect detection means, high-quality scientific research persons, high-quality tracking service, and face customers with highly dedicated spirit. It is constantly rated "advanced quality management enterprise" and "value-contract and keep-credibility enterprise" for many years. We has been keeping the attitude that only customers are satisfied, can we are satisfied to keep pace with the times. We have many skilled technical persons and experienced after-sales service team, so we can offer customers a full of crushing screening from monomer to solutions. And we can provide customers with professional technology support, reliable supply of spare parts and high quality of after-sales service.
