Home > Products > Vibrating feeder > Oscillating feeder, vibrating sand feeder, sand processing machines

Oscillating feeder, vibrating sand feeder, sand processing machines

Name: Oscillating feeder, vibrating sand feeder, sand processing machines
Brand: Hongyun
Availability: InStock

FOB Price

US$ 9,700 - 10,000 / Set

1 Set(Min. Order)

Port Dalian Qingdao Shanghai Lianyungang and all inland ports
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Coal,ore, sand production line, stone
Power Type	Electric	Capacity(t/h)	40t/h
Place of Origin	Henan, China	Brand Name	Hongyun
Model Number	GZG403	Power(W)	2*0.25kw
Dimension(LWH)	4001000200mm	Weight	172kg
Certification	CE ISO	Warranty	1 Year
After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

According to the customer's requirements.

Product Description

Oscillating feeder, vibrating sand feeder, sand processing machines

Brand
Hongyun
Type
Vibrating feeder
Capacity
40-1000 t/h
Feed Size
100-500 mm
Processed Materials
Pebbles, granite, basalt, iron ore, limestone, quartz stone, gangue, construction waste.
Applications
Sand making station, concrete sand making, dry mixed mortar, machine-made sand, desulfurationof power plant, silica sand etc.
Brief Introduction
Vibrating Feeder is mainly used to feed materials evenly and continuously into belt conveyor, bucket elevator, screening and crushing equipment before primary crusher, also used for screening fine materials to increase the processing capacity of crusher. The feeding amount can be adjusted flexibly to achieve centralized control and automatic control in the production process.
Features
1. Stable vibration, reliable operation, low energy consumption and low noise. 2. The fence distance can be adjusted, special design of fence can prevent material blocking. 3. Adjustable speed motor is applied to control feeding capacity easily and avoid frequent motor re-start.

Parameters

Model	Size of feeding trough(L×W×H)(mm)	Production capacity (t/h)		Max.feeding size (mm)	Double amplitude (mm)	Vibrator model	Current (A)	Power (KW)	Weight (Kg)
		Level angle	-10
GZG403	400×1000×200	30	40	100	4	ZG405	2×0.73	2×0.25	171
GZG503	500×1000×200	60	85	150	4	ZG405	2×0.73	2×0.25	202
GZG633	630×1250×250	110	150	200	4	ZG410	2×1.53	2×0.55	379
GZG703	700×1029×250	120	170	200	4	ZG410	2×1.53	2×0.55	389
GZG803	800×1500×250	160	230	250	4	ZG415	2×1.95	2×0.75	563
GZG903	900×1483×250	180	250	250	4	ZG415	2×1.95	2×0.75	613
GZG1003	1000×1750×250	270	380	300	4	ZG420	2×2.71	2×1.1	762
GZG1103	1100×1673×250	300	420	300	4	ZG420	2×2.71	2×1.1	854
GZG1253	1250×2000×315	460	650	350	4	ZG432	2×3.51	2×1.5	1099
GZG1303	1300×2040×300	480	670	350	4	ZG432	2×3.51	2×1.5	1117
GZG1503	1500×2250×300	720	1000	500	3.5	ZG440	2×5.19	2×2.2	1477
GZG1603	1600×2500×315	770	1100	500	4	ZG450	2×6.82	2×3.0	1555
GZG1803	1800×2325×375	900	1200	500	3	ZG450	2×6.82	2×3.0	2350
GZG2003	2000×3000×400	1000	1400	500	2.5	ZG450	2×6.82	2×3.0	2705
GZG705	700×1029×250	130	180	200	5	ZG609	2×1.66	2×0.55	385
GZG805	800×1500×250	170	250	250	5	ZG609	2×1.66	2×0.55	510
GZG905	900×1483×250	200	270	250	5	ZG609	2×1.66	2×0.55	561
GZG1005	1000×1750×250	290	410	300	5	ZG612	2×2.14	2×0.75	652
GZG1105	1100×1673×250	320	450	300	5	ZG618	2×2.97	2×1.1	795
GZG1255	1250×25000×315	500	700	350	5	ZG618	2×2.97	2×1.1	1002
GZG1305	1300×2040×300	520	720	350	5	ZG625	22×3.84	2×1.5	1070
GZG1505	1500×2250×300	780	1080	500	5	ZG636	2×5.55	2×2.2	1414
GZG1605	1600×2500×315	830	1190	500	5	ZG636	2×5.55	2×2.2	1720

Details

Related machines

FAQ

1, warranty: 1 year

2, Install: We providing engineer

3, Design plant: Our engineer will design it for you, this is free
