Specifications
1. Good performance2. High efficiency and low cost
3. Excellent hydraulic system
4. simple operation and repair
Characteristics:
1.This serial 4-column hydraulic press has a wide popularity, it can applied into various compressing craft of plastic material, like bending, turn-up,sheet stretching,also it can applied into revising,press fitting. It has applied popular in abrasive material industry,fire-proof material.powder metallurgy and etc.If the machine is applied in the inputting or punching, the customer need to order the blanking
cushion device to eliminate or ease the impacting and noise in the moment of broking the material.
2.This serial hydraulic press has independent motive structure and electric system. With the use of
button central control, it can achieve three operating method as regulating (inching), manual and
semi-automatic.
3.The working pressure, compressing speed, the stroke range of fast down stroking and slow down
of this serial hydraulic press all can be regulated according the craft requirements; also it can achieve
two craft method as fixed-pressure forming and fixed-distance forming. The craft of fixed-pressure forming can maintain pressure, defer and return stroke automatically. Maintaining pressure
has two different choices as machine halt pressure maintaining and
non-halt machine pressure maintaining.
ltem |
Unit | EY32 Series 4-column (general type) hydraulic press | |||||||||||||||||
EY32-25 | EY32-40A | EY32-63A | EY32-100 | EY32-100B | EY32-200 | EY32-200A | EY32-315A | EY32-315F | EY32-400A | EY32-500B | EY32-500 | EY32-630 | EY32-800 | EY32-1000 | EY32-2500 | EY32-4000 | |||
Nominal Force | KN | 250 | 400 | 630 | 1000 | 1000 | 2000 | 2000 | 3150 | 3150 | 4000 | 5000 | 5000 | 6300 | 8000 | 10000 | 25000 | 40000 | |
Ejecting force | KN | 60 | 100 | 160 | 300 | 190 | 400 | 300 | 400 | 630 | 630 | 1000 | 1000 | 1000 | 1250 | 2000 | 2500 | 4000 | |
Return Stroke | KN | 110 | 150 | 125 | 160 | 320 | 360 | 360 | 600 | 600 | 830 | 930 | 930 | 850 | 720 | 1060 | 2000 | 4360 | |
Max. working pressure | MPa | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
Ram stroke | mm | 250 | 320 | 500 | 630 | 600 | 710 | 710 | 800 | 800 | 800 | 900 | 900 | 1000 | 1000 | 1000 | 1000 | 1000 | |
Ejecting stroke | mm | 125 | 150 | 160 | 200 | 200 | 250 | 200 | 250 | 300 | 300 | 300 | 300 | 300 | 350 | 450 | 500 | 500 | |
Daylight | mm | 450 | 520 | 800 | 900 | 900 | 1120 | 1120 | 1250 | 1250 | 1250 | 1500 | 1500 | 1600 | 1600 | 1600 | 2000 | 1700 | |
Speed | ldle | mm/s | 45 | 55 | 115 | 120 | 22 | 120 | 100 | 70 | 120 | 120 | 120 | 120 | 120 | 150 | 150 | 150 | 150 |
Pressing | mm/s | 10~22 | 10~35 | 10~22 | 6~15 | 6~15 | 7~18 | 5~18 | 6~12 | 6~12 | 7~18 | 7~15 | 7~15 | 6~12 | 6~12 | 5~12 | 3~5 | 5 | |
Return | mm/s | 55 | 105 | 105 | 90 | 45 | 100 | 100 | 60 | 60 | 92 | 80 | 80 | 80 | 120 | 100 | 74 | 55 | |
