Home > Manufacturing & Processing Machinery > Machine Tools > Punching Machine > EY28 Series Four-column Double-action Hydraulic Press
US$ 1 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Power Source:
Hydraulic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Press Machine, EY81F- 400 Hydraulic Metal BalerNegotiableMOQ: 1 Set -
EY81F-63 Hydraulic Baler, Universal Milling MachineNegotiableMOQ: 1 Set
-
PACKING MACHINE, EY81 Scrap Metal BalerNegotiableMOQ: 1 Set
-
EY71 Series Glass-ware Hydraulic PressNegotiableMOQ: 1 Set
-
Hydraulic Alligator ShearsNegotiableMOQ: 1 Unit
Condition
New
CNC or Not
Normal
Power Source
Hydraulic
Place of Origin
Jiangsu, China
Brand Name
Gaintally
Specifications
1. good performance2. excellent hydraulic system
3.easy operation and repair
The series is double-action hydraulic press, especially used for sheet metal process such as drawing, flanging and bending, etc. It can also be available for general purposes.
Its operation is easy with two-cartridge valve in hydraulic system and PLC control in electric system.
With advantages of high idle speed and adjustable blank-holding force, it would be your ideal equipment to process sheet metal.
| No. | Item | Type Unit | EJY28-400/630 | EJY28-500/800 | EJY28-630/1030 | |
| 1 | Main pressure force | kN | 6300 | 8000 | 10300 | |
| 2 | Drawing ram force | kN | 4000 | 5000 | 6300 | |
| 3 | Press ram blank force | kN | 2300 | 3000 | 4000 | |
| 4 | Hydraulic cushion force | kN | 1500 | 2000 | 2400 | |
| 5 | Drawing ram return force | kN | 500 | 700 | 700 | |
| 6 | Press ram return force | kN | 500 | 700 | 700 | |
| 7 | Hydraulic cushion ejecting stroke | kN | 500 | 630 | 800 | |
| 8 | Liquid max pressure | Mpa | 25 | 25 | 25 | |
| 9 | Drawing max distance between ram to table | mm | 1700 | 2000 | 2200 | |
| 10 | Max distance between blank ram to table | mm | 1700 | 2000 | 2200 | |
| 11 | Drawing ram max stroke | mm | 1000 | 1100 | 1300 | |
| 12 | Pressing ram max stroke | mm | 1000 | 1100 | 1300 | |
| 13 | Hydraulic cushion stroke | mm | 300 | 350 | 400 | |
| 14 | Pressing ram size | mm | 2500×1800 | 3000×2000 | 3200×2200 | |
| 15 | Hydraulic cushion size | mm | 1800×1200 | 2300×1400 | 2500×1500 | |
| 16 | cam block drawing size | right and left | mm | 1800 | 2300 | 2500 |
| front and rear | mm | 1200 | 1400 | 1500 | ||
| 17 | Worktable size | right and left | mm | 2500 | 3000 | 3200 |
| front and rear | mm | 1800 | 2000 | 2200 | ||
| 18 | cam block drawing speed | fast down speed | mm/s | 300 | 300 | 300 |
| drawing speed | mm/s | 10-45 | 10-45 | 10-45 | ||
| return stroke | mm/s | 200 | 200 | 200 | ||
| 19 | Camblock speed | fast down speed | mm/s | 300 | 300 | 300 |
| working | mm/s | 10-45 | 10-45 | 10-45 | ||
| return stroke | mm/s | 200 | 200 | 200 | ||
| 20 | power | kW | 120 | 160 | 180 | |
| 21 | weight | t | 130 | 160 | ||
