Specifications
1.Safe & reliable2.No footing bolts needed
3.Diesel engine can be equipped for power
HBS Waste Car Baler for Sale
Applications:
The hydraulic baler & shear machinery is suitable for the cutting of scrap materials. Metal pieces are pressed 2- or 3-dimensionally by using the pressing lid, wing and feeding pusher, and cut or broken into pieces.
The machine is able to :
1. Pre-compress and cut scrap
2.Cut bars and profiles
3. Package light scrap
4. Squeeze and cut car bodies
No. |
Technical Specification |
Remark |
||||||||
1 |
Cutting Cylinder |
Model |
YG400/280-650 |
stroke |
650mm |
|
||||
Max. Force |
4000KN |
Quantity |
1piece |
|
||||||
2 |
Press Cylinder |
Model |
YG220/160-600 |
Stroke |
600mm |
|
||||
Max. Force |
1050KN |
Quantity |
1piece |
|
||||||
3 |
Side Press Cylinder (Grade one) |
Model |
YG200/140-480 |
Stroke |
480mm |
|
||||
Max. Coving Force |
800KN*2 |
Quantity |
2 pieces |
|
||||||
4 |
Side Press Cylinder (Grade two) |
Model |
YG200/140-480 |
Stroke |
480mm |
|
||||
Max. Pushing Force |
800KN*2 |
Quantity |
2pieces |
|
||||||
5 |
Material Pushing Cylinder |
Model |
YG200/140-4800 |
Stroke |
4800mm |
|
||||
Max. Pushing Force |
800KN |
Quantity |
1 piece |
|
||||||
6 |
Press Box Size(L*W*H)
|
5000*1600*900mm |
|
|||||||
7 |
Bale Size(L*W*H)
|
700*500mm |
|
|||||||
8 |
Hydraulic System Pressure |
25 MPa |
|
|||||||
9 |
Total Motor |
110KW |
|
|||||||
10 |
Power |
380V/3PH,50Hz |
|
|||||||
11 |
Blade Length |
800mm |
|
|||||||
12 |
Shearing Frequency (times/min) |
3-5 time/min |
|
|||||||
13 |
Capacity(Ton/Hour) |
4-12 |
|
|||||||
14 |
Max Cutting Force (material Tensile Strength no more than 440MPa) |
Round TeelΦ120mm |
|
|||||||
Billet 110*110mm | ||||||||||
Steel Plate 50*600mm | ||||||||||
15 |
Motor |
Model |
Y200L2-6 |
Nominal Power |
55KW |
|
||||
Nominal Speed |
970rmp |
Quantity |
2 pieces |
|
||||||
16 |
Hydraulic Pump |
Model |
250YCY14-1B |
Nominal Pressure |
31.5MPa |
|
||||
Nominal Outflow |
250ml/r |
Quantity |
2 Pieces |
|
||||||
17 |
Equipment Outline Dimension
|
11300*2800*3500(Flank Expansion) |
L*W*H |
|||||||
11300*2200*3500mm(Flank Collapsed) |
L*W*H |
|||||||||
18 |
Floor Space |
14000*4000mm |
L*W |
|||||||
19 |
Control System |
PLC Automatic Control |
|
|||||||
20 |
Cooling System |
Oil - steam heat exchanger
|
||||||||
