hot sale scrap metal baler manufacturer
NO | TECHNICAL SPECIFICATIONS | REMARKS | |||||
1 | Main Cylinder | Model | YG320/220-700 | Quantity | 1 PCS |
| |
Nominal Force | 2000KN | Stroke | 700mm |
| |||
2 | Side Cylinder | Model | YG250/180-1250 | Quantity | 1 PCS |
| |
Nominal Force | 1250KN | Stroke | 1250mm |
| |||
3 | Top Cover Cylinder | Model | YG180/120-1160 | Quantity | 1 PCS |
| |
Nominal Force | 630KN | Stroke | 1160mm |
| |||
4 | Bale Turn Out Cylinder | Model | YG125/80-395 | Quantity | 1 PCS |
| |
Nominal Force | 80KN | Stroke | 395mm |
| |||
5 | Hydraulic System Pressure | 25MPA (Bale-discharging 6MPA) |
| ||||
6 | Press Box Size | 1600*1000*800mm | L*W*H | ||||
7 | Bale Size | (~550)*400*400mm | L*W*H | ||||
8 | Cycle Length | App. 100 Sec |
| ||||
9 | Hydraulic Pump | Model | 160YCY14-1B | Quantity | 1 set |
| |
Nominal Outflow | 160ml/r | Nominal Pressure | 31.5MPA |
| |||
10 | Motor | Model | Y200L2-6 | Quantity | 1 set |
| |
Nominal Power | 22KW | Nominal Speed | 970rpm |
| |||
Applications:
HC81 series of hydraulic metal balers are applicable in steel plants,recycling companies,ferrous&non-ferrous
smelting industry to press metal scrap (steel,copper,aluminium,stainless
steel,discarded automobiles) into acceptable furnace charges(shapes:cuboid,cylinder
or octagon),so as to reduce cost of transportation,and
increase speed of furnace charging.
Features:
1,Hydraulic drive for all machine types, manual valve control or PLC control .
2,Bale-discharging:"turn-out","push-out","forward-out" or manual discharging.
3,No footing bolts needed in installation;diesel engine can be equipped for power.
4,Baling force 10 grades from 63 to 400 tons;productivity from 4 to 40 tons per shift
( 8 hours )
5,Press box size,bale size & bale shape can be customized.
Production Process
GAODE Hydraulic Machinery has been a trusted name in the waste recycling equipment industry for over a decade as a dedicated Chinese manufacturer of scrap metal recycling equipment, our flagship products includethe shear baler, scrap baler, scrap shear, and recycling crane. In addition to scrap metal processing equipment, we also supply horizontal baler and vertical baler for compacting plastic, paper, cardboard, straw, textile and more types of wastes.
Our company was first inaugurated in 2003.We have combined advanced production and testing instruments with state-of-the-art manufacturing techniques to yield outstanding product quality.
Our GAODE brand has received critical acclaim both domestically and overseas. As a trusted waste recycling equipment manufacturer, we have successfully passed the certification of both the TUV and the ISO9001 Quality Management System. We are currently in the process of obtaining the approval of European standards such as CE and UL.
Company Show
The Finished Products
Fair Show
Certification
6months guarantee for whole machine
24hours technical support by email
Calling or door to door service
User manual and detailed video
Q1:Can I add my logo on the machines?
A: Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q2:How can i get the after-service?
A: We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems,we also send the spare parts,but you should pay.
Q3:Do you have inspection procedures for machines?
A:100% self-inspection before packing
Q4:Can I have a visit to your factory before the order?
A:Sure,welcome to visit our factory.
Here is our factory address:No.691, Chengshan Road, Jiangyin City, Jiangsu Province, China.
Q5: Can we order one set machine?
A:Yes, you can.
Suke
Skype: gaode.suke
Sales representative
Jiangsu Gaode Hydraulic Machinery Co.,Ltd
China factory
ADD: No. 691 Chengshan Road, Jiangyin City, Jiangsu Province.
Tel: +86 15251557803(24 hours service) | Fax: +86 510 8699399
