Specification:
No. | Parameter | Ps | |||||||
1 | Main Cylinder | Model | YG180/120-305 | 1set | |||||
Nominal Thrust | 630KN | Stroke | 305MM |
| |||||
2 | Side Cylinder | Model | YG180/120-730 | 1set | |||||
Nominal Thrust | 630KN | Stroke | 730MM |
| |||||
3 | Cover Cylinder | Model | YG110/75-730 | 1set | |||||
Nominal Thrust | 260KN | Stroke | 730MM |
| |||||
4 | Turn-out Clinder | Model | YG100/65-340 | 1set | |||||
Nominal Thrust | 80KN | Stroke | 340MM |
| |||||
5 | Press box(L×W×H)(MM) | 1000*600*500 |
| ||||||
6 | Bale size(L×W×H)(MM) | (~300)*300*300 |
| ||||||
7 | Work press(Mpa) | 21.5 Mpa |
| ||||||
8 | Bale dentisy(Kg/m3) | ≥2000(Fe) |
| ||||||
9 | Cycle Time | ≥90S |
| ||||||
10 | Motor | Model | Y132M-4 | Power | 7.5KW |
| |||
Speed | 1470r/min | Nos | 1set |
| |||||
12 | Pump | Model | 25YCY14-1B | Press | 31.5Mpa |
| |||
Flux | 25ml/r | Nos | 1set | ||||||
Features:
1, Hydraulic drive for all machine types, manual valve control or PLC control .
2, Bale-discharging:turn-out push-out forward-out or manual discharging.
3, No footing bolts needed in installation ; diesel engine can be equipped for power.
4, Baling force 10 grades from 63 to 400 tons ; productivity from 4 to 40 tons per shift
( 8 hours )
5, Press box size, bale size & bale shape can be customized
Applications:
HC81 series of hydraulic metal balers are applicable in steel plants, recycling companies,
ferrous &non-ferrous smelting industry to press metal scraps (steel, copper, aluminum, stainless steel, discarded automobiles)
into acceptable furnace charges (shapes: cuboid, cylinder or octagon),
so as to reduce cost of transportation, to increase speed of furnace charging
Packaging: in nude wrapped with plastic film
Shipping port: Shanghai
A variety of team activities:
Guarantee and after-sale service
6months guarantee for whole machine
24hours technical support by email
Calling or door to door service
User manual and detailed video
