PET strap making machine/PET strap production line
1. General description of PET strap making machine
Processing material: 100% recycled PET flakes or virgin PET (I.V ≥0.75)
Product width: 9-25mm
Strap thickness: 0.5-1.2mm
Quantity of extruded straps: 2
Max output: 150kg/h
Max Liner speed: 120m/min
Power supply: 380V/3P/50Hz
Installed power: 280KW (production power: about 130KW)
Operators: 2-3workers
Overall dimension: 45m×3m×4.2m
2.Main parameters of PET strap making machine
Model |
SJ65/33 |
SJ75/33 |
SJ90/33 |
|
Band number |
One |
Two |
Two |
|
Band specification |
9.5~19mm(Width) 0.5-1.20mm(Thickness) |
|||
Output |
50kg/h |
100kg/h |
150kg/h |
|
Water flux |
0.6 m3/h |
|||
Water pipe diameter |
DN15 DN20, DN50 |
|||
Compressed Air flux |
0.25 m3/min |
|||
Compressed Air pressure |
0.6Mpa |
|||
Total Power |
132kw |
186kw |
285kw |
|
The length of production line |
25-28m |
28-32m |
35-40m |
|
Power |
Three-phase four-wire system |
|||
3. More photos for your reference
