Home > Industrial Equipment & Components > Refrigeration Equipment > Industrial Chiller > Water Chiller/industrial Water Cooling Machine
US$ 1,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
new
Type:
Other, air cooled/water cooled
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Baler MachineNegotiableMOQ: 1 Set -
Blade Sharpen Machine/blade Sharpening MachineNegotiableMOQ: 1 Set
-
Plastic Dryer/plastic Mixing Dryer/plastic Dehumidify MachineUS$ 2,000 - 10,000MOQ: 1 Set
-
Soft Pvc Pipe Winder Machine/pe Pipe WinderNegotiableMOQ: 1 Set
-
Inkjet Printers for PE PipeNegotiableMOQ: 1 Set
Condition
new
Type
Other, air cooled/water cooled
Place of Origin
Jiangsu, China
Brand Name
sevenstars
Model Number
MG-10W
Cooling Capability(kw)
9.85KW
Voltage
3PH-220V/380V-50HZ/60HZ
Dimension(L*W*H)
1170mm*710mm*1200mm
Weight
CE ISO
Certification
CE
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Water Chiller1.SANYO/COMPELAND compressor
2.Direct selling, OEM offered
3.Cooling capacity custom
4.CE
Industrial Water Cooled Chiller
MG-series water-cooled industrial chiller is a new generation of refrigeration equipment, mainly used for the steel, medicine, electronics, chemical industry, food industry and other special industry.
1.Power supply:3PH-200V/220V/380V/415V-50HZ/60HZ
2.Refrigerant R22/R/134/407c
3.Set temperature range: From 0 to +50°C
4.Cooling capacity: 1HP-240HP (0.7tons-206tons)
5.Compressor type:Screw type,Scroll type
6.Compressor brand: SANYO, COPELAND, DANFOSS, HANBELL.DAIKIN, HITACHI
| Specification model | Unit | MG-10W(D) |
| Nominal cooling capacity | kcal/h 50HZ/60HZ | 25800 30960 |
| KW 50HZ/60HZ | 30 36 | |
| Input power | KW | 9.85 |
| Set temp. range | 0ºC~50ºC | |
| Power supply | 3PH-380V-50HZ (200V/220V/415V-50HZ/60HZ) | |
| Refrigerant | Type | R22/R134a/407c |
| Type of control | Thermostatic expansion valve | |
| Compressor | Type | Hermetic scroll |
| Power(kw) | 4.55*2 | |
| Condenser | Type | shell and tube |
| Cooling water flow(m3/h) | 6.76 7.4 | |
| Inlet and outlet pipe diameter(inch) | 1-1/2" | |
| Evaporator | Type | Tank with coil/shell and tube |
| Chilled fluid flow(m3/h) | 5.26 6.32 | |
| Volume(L) | 200 | |
| Inlet and outlet pipe diameter(inch) | 1-1/2" | |
| Pump | Power(kw) | 0.75 |
| Lift(m) | 20 | |
| Dimension | Length(mm) | 1170 |
| Wide(mm) | 710 | |
| High(mm) | 1200 | |
| Weight | kg | 430 |
| Safety protection | compressor over temperature,over current,high and low pressure,Phase sequence,phase-missing | |
water chiller industrial water cooling machine
Send Inquiry to This Supplier
* Email
Want the best price?
Post an RFQ now!
Business Type
Manufacturer, Trading Company
Year Established
2006
Factory Size
10,000-30,000 square meters
Total Employees
51 - 100 People
